Collaboration diagram for Base API:

Detailed Description

Macros
#define	__CHIBIOS_NIL__
	ChibiOS/NIL identification macro. More...

#define	CH_KERNEL_STABLE 0
	Stable release flag. More...

#define	THD_IDLE_BASE (&__main_thread_stack_base__)

#define	__CH_STRINGIFY(a) #a
	Utility to make the parameter a quoted string. More...

#define	THD_WORKING_AREA_END(wa) ((wa) + ((sizeof wa) / sizeof (stkalign_t)))
	Returns the top address of a working area. More...

ChibiOS/NIL version identification
#define	CH_KERNEL_VERSION "4.1.0"
	Kernel version string. More...

#define	CH_KERNEL_MAJOR 4
	Kernel version major number. More...

#define	CH_KERNEL_MINOR 1
	Kernel version minor number. More...

#define	CH_KERNEL_PATCH 0
	Kernel version patch number. More...

Constants for configuration options
#define	FALSE 0
	Generic 'false' preprocessor boolean constant. More...

#define	TRUE 1
	Generic 'true' preprocessor boolean constant. More...

Wakeup messages
#define	MSG_OK (msg_t)0
	OK wakeup message. More...

#define	MSG_TIMEOUT (msg_t)-1
	Wake-up caused by a timeout condition. More...

#define	MSG_RESET (msg_t)-2
	Wake-up caused by a reset condition. More...

Special time constants
#define	TIME_IMMEDIATE ((sysinterval_t)-1)
	Zero time specification for some functions with a timeout specification. More...

#define	TIME_INFINITE ((sysinterval_t)0)
	Infinite time specification for all functions with a timeout specification. More...

#define	TIME_MAX_INTERVAL ((sysinterval_t)-2)
	Maximum interval constant usable as timeout. More...

#define	TIME_MAX_SYSTIME ((systime_t)-1)
	Maximum system of system time before it wraps. More...

Thread state related macros
#define	NIL_STATE_WTSTART (tstate_t)0
	Thread not yet started or terminated. More...

#define	NIL_STATE_READY (tstate_t)1
	Thread ready or executing. More...

#define	NIL_STATE_SLEEPING (tstate_t)2
	Thread sleeping. More...

#define	NIL_STATE_SUSPENDED (tstate_t)3
	Thread suspended. More...

#define	NIL_STATE_WTEXIT (tstate_t)4
	Waiting a thread. More...

#define	NIL_STATE_WTQUEUE (tstate_t)5
	On queue or semaph. More...

#define	NIL_STATE_WTOREVT (tstate_t)6
	Waiting for events. More...

#define	NIL_STATE_WTANDEVT (tstate_t)7
	Waiting for events. More...

#define	NIL_STATE_SNDMSGQ (tstate_t)8
	Sending a message, in queue. More...

#define	NIL_STATE_WTMSG (tstate_t)10
	Waiting for a message. More...

#define	NIL_STATE_FINAL (tstate_t)11
	Thread terminated. More...

#define	NIL_THD_IS_WTSTART(tp) ((tp)->state == NIL_STATE_WTSTART)

#define	NIL_THD_IS_READY(tp) ((tp)->state == NIL_STATE_READY)

#define	NIL_THD_IS_SLEEPING(tp) ((tp)->state == NIL_STATE_SLEEPING)

#define	NIL_THD_IS_SUSPENDED(tp) ((tp)->state == NIL_STATE_SUSPENDED)

#define	NIL_THD_IS_WTEXIT(tp) ((tp)->state == NIL_STATE_WTEXIT)

#define	NIL_THD_IS_WTQUEUE(tp) ((tp)->state == NIL_STATE_WTQUEUE)

#define	NIL_THD_IS_WTOREVT(tp) ((tp)->state == NIL_STATE_WTOREVT)

#define	NIL_THD_IS_WTANDEVT(tp) ((tp)->state == NIL_STATE_WTANDEVT)

#define	NIL_THD_IS_SNDMSGQ(tp) ((tp)->state == NIL_STATE_SNDMSGQ)

#define	NIL_THD_IS_WTMSG(tp) ((tp)->state == NIL_STATE_WTMSG)

#define	NIL_THD_IS_FINAL(tp) ((tp)->state == NIL_STATE_FINAL)

#define	CH_STATE_NAMES

RT options not existing in NIL
#define	CH_CFG_USE_REGISTRY FALSE

Kernel types
typedef port_rtcnt_t	rtcnt_t

typedef port_syssts_t	syssts_t

typedef port_stkalign_t	stkalign_t

typedef uint8_t	tstate_t

typedef uint32_t	tprio_t

typedef int32_t	msg_t

typedef int32_t	eventid_t

typedef uint32_t	eventmask_t

typedef uint32_t	eventflags_t

typedef int32_t	cnt_t

typedef uint32_t	ucnt_t

Threads tables definition macros
#define	THD_TABLE_BEGIN const thread_descriptor_t nil_thd_configs[] = {
	Start of user threads table. More...

#define	THD_TABLE_THREAD(_prio, _name, _wap, _funcp, _arg)
	Entry of user threads table. More...

#define	THD_TABLE_END
	End of user threads table. More...

Memory alignment support macros
#define	MEM_ALIGN_MASK(a) ((size_t)(a) - 1U)
	Alignment mask constant. More...

#define	MEM_ALIGN_PREV(p, a) ((size_t)(p) & ~MEM_ALIGN_MASK(a))
	Aligns to the previous aligned memory address. More...

#define	MEM_ALIGN_NEXT(p, a)
	Aligns to the new aligned memory address. More...

#define	MEM_IS_ALIGNED(p, a) (((size_t)(p) & MEM_ALIGN_MASK(a)) == 0U)
	Returns whatever a pointer or memory size is aligned. More...

#define	MEM_IS_VALID_ALIGNMENT(a) (((size_t)(a) != 0U) && (((size_t)(a) & ((size_t)(a) - 1U)) == 0U))
	Returns whatever a constant is a valid alignment. More...

Working Areas
#define	THD_WORKING_AREA_SIZE(n)
	Calculates the total Working Area size. More...

#define	THD_WORKING_AREA(s, n) PORT_WORKING_AREA(s, n)
	Static working area allocation. More...

Threads abstraction macros
#define	THD_FUNCTION(tname, arg) PORT_THD_FUNCTION(tname, arg)
	Thread declaration macro. More...

ISRs abstraction macros
#define	CH_IRQ_IS_VALID_PRIORITY(prio) PORT_IRQ_IS_VALID_PRIORITY(prio)
	Priority level validation macro. More...

#define	CH_IRQ_IS_VALID_KERNEL_PRIORITY(prio) PORT_IRQ_IS_VALID_KERNEL_PRIORITY(prio)
	Priority level validation macro. More...

#define	CH_IRQ_PROLOGUE()
	IRQ handler enter code. More...

#define	CH_IRQ_EPILOGUE()
	IRQ handler exit code. More...

#define	CH_IRQ_HANDLER(id) PORT_IRQ_HANDLER(id)
	Standard normal IRQ handler declaration. More...

Fast ISRs abstraction macros
#define	CH_FAST_IRQ_HANDLER(id) PORT_FAST_IRQ_HANDLER(id)
	Standard fast IRQ handler declaration. More...

Time conversion utilities
#define	TIME_S2I(secs) ((sysinterval_t)((time_conv_t)(secs) * (time_conv_t)CH_CFG_ST_FREQUENCY))
	Seconds to time interval. More...

#define	TIME_MS2I(msecs)
	Milliseconds to time interval. More...

#define	TIME_US2I(usecs)
	Microseconds to time interval. More...

#define	TIME_I2S(interval)
	Time interval to seconds. More...

#define	TIME_I2MS(interval)
	Time interval to milliseconds. More...

#define	TIME_I2US(interval)
	Time interval to microseconds. More...

Threads queues
#define	__THREADS_QUEUE_DATA(name) {(cnt_t)0}
	Data part of a static threads queue object initializer. More...

#define	THREADS_QUEUE_DECL(name) threads_queue_t name = __THREADS_QUEUE_DATA(name)
	Static threads queue object initializer. More...

Macro Functions
#define	chSysGetRealtimeCounterX() (rtcnt_t)port_rt_get_counter_value()
	Returns the current value of the system real time counter. More...

#define	chSysDisable()
	Raises the system interrupt priority mask to the maximum level. More...

#define	chSysSuspend()
	Raises the system interrupt priority mask to system level. More...

#define	chSysEnable()
	Lowers the system interrupt priority mask to user level. More...

#define	chSysLock()
	Enters the kernel lock state. More...

#define	chSysUnlock()
	Leaves the kernel lock state. More...

#define	chSysLockFromISR()
	Enters the kernel lock state from within an interrupt handler. More...

#define	chSysUnlockFromISR()
	Leaves the kernel lock state from within an interrupt handler. More...

#define	chSchGoSleepS(newstate) chSchGoSleepTimeoutS(newstate, TIME_INFINITE)
	Puts the current thread to sleep into the specified state. More...

#define	chSchWakeupS(ntp, msg)
	Wakes up a thread. More...

#define	chSchIsRescRequiredI() ((bool)(nil.current != nil.next))
	Evaluates if a reschedule is required. More...

#define	chThdGetSelfX() nil.current
	Returns a pointer to the current `thread_t`. More...

#define	chThdGetPriorityX(void) (tprio_t)(nil.current - &nil.threads[0])
	Returns the current thread priority. More...

#define	chThdResumeS(trp, msg)
	Wakes up a thread waiting on a thread reference object. More...

#define	chThdSleepSeconds(secs) chThdSleep(TIME_S2I(secs))
	Delays the invoking thread for the specified number of seconds. More...

#define	chThdSleepMilliseconds(msecs) chThdSleep(TIME_MS2I(msecs))
	Delays the invoking thread for the specified number of milliseconds. More...

#define	chThdSleepMicroseconds(usecs) chThdSleep(TIME_US2I(usecs))
	Delays the invoking thread for the specified number of microseconds. More...

#define	chThdSleepS(timeout) (void) chSchGoSleepTimeoutS(NIL_STATE_SLEEPING, timeout)
	Suspends the invoking thread for the specified time. More...

#define	chThdSleepUntilS(abstime)
	Suspends the invoking thread until the system time arrives to the specified value. More...

#define	chThdQueueObjectInit(tqp) ((tqp)->cnt = (cnt_t)0)
	Initializes a threads queue object. More...

#define	chThdQueueIsEmptyI(tqp) ((bool)(tqp->cnt >= (cnt_t)0))
	Evaluates to `true` if the specified queue is empty. More...

#define	chVTGetSystemTimeX() (nil.systime)
	Current system time. More...

#define	chVTTimeElapsedSinceX(start) chTimeDiffX((start), chVTGetSystemTimeX())
	Returns the elapsed time since the specified start time. More...

#define	chVTIsSystemTimeWithinX(start, end) chTimeIsInRangeX(chVTGetSystemTimeX(), start, end)
	Checks if the current system time is within the specified time window. More...

#define	chTimeAddX(systime, interval) ((systime_t)(systime) + (systime_t)(interval))
	Adds an interval to a system time returning a system time. More...

#define	chTimeDiffX(start, end) ((sysinterval_t)((systime_t)((systime_t)(end) - (systime_t)(start))))
	Subtracts two system times returning an interval. More...

#define	chDbgCheck(c)
	Function parameters check. More...

#define	chDbgAssert(c, r)
	Condition assertion. More...

Typedefs
typedef uint32_t	systime_t
	Type of system time. More...

typedef uint32_t	sysinterval_t
	Type of time interval. More...

typedef uint64_t	time_conv_t
	Type of time conversion variable. More...

typedef struct nil_os_instance	os_instance_t
	Type of a structure representing the system. More...

typedef void(*	tfunc_t) (void *p)
	Thread function. More...

typedef struct nil_thread_descriptor	thread_descriptor_t
	Type of a thread descriptor. More...

typedef struct nil_thread	thread_t
	Type of a structure representing a thread. More...

typedef thread_t *	thread_reference_t
	Type of a thread reference. More...

typedef struct nil_threads_queue	threads_queue_t
	Type of a queue of threads. More...

typedef threads_queue_t	semaphore_t
	Type of a structure representing a semaphore. More...

Data Structures
struct	nil_threads_queue
	Structure representing a queue of threads. More...

struct	nil_thread_descriptor
	Structure representing a thread descriptor. More...

struct	nil_thread
	Structure representing a thread. More...

struct	nil_os_instance
	System data structure. More...

Functions
thread_t *	nil_find_thread (tstate_t state, void *p)
	Retrieves the highest priority thread in the specified state and associated to the specified object. More...

cnt_t	nil_ready_all (void *p, cnt_t cnt, msg_t msg)
	Puts in ready state all thread matching the specified status and associated object. More...

void	__dbg_check_disable (void)
	Guard code for `chSysDisable()`. More...

void	__dbg_check_suspend (void)
	Guard code for `chSysSuspend()`. More...

void	__dbg_check_enable (void)
	Guard code for `chSysEnable()`. More...

void	__dbg_check_lock (void)
	Guard code for `chSysLock()`. More...

void	__dbg_check_unlock (void)
	Guard code for `chSysUnlock()`. More...

void	__dbg_check_lock_from_isr (void)
	Guard code for `chSysLockFromIsr()`. More...

void	__dbg_check_unlock_from_isr (void)
	Guard code for `chSysUnlockFromIsr()`. More...

void	__dbg_check_enter_isr (void)
	Guard code for `CH_IRQ_PROLOGUE()`. More...

void	__dbg_check_leave_isr (void)
	Guard code for `CH_IRQ_EPILOGUE()`. More...

void	chDbgCheckClassI (void)
	I-class functions context check. More...

void	chDbgCheckClassS (void)
	S-class functions context check. More...

void	chSysInit (void)
	Initializes the kernel. More...

void	chSysHalt (const char *reason)
	Halts the system. More...

void	chSysTimerHandlerI (void)
	Time management handler. More...

void	chSysUnconditionalLock (void)
	Unconditionally enters the kernel lock state. More...

void	chSysUnconditionalUnlock (void)
	Unconditionally leaves the kernel lock state. More...

syssts_t	chSysGetStatusAndLockX (void)
	Returns the execution status and enters a critical zone. More...

void	chSysRestoreStatusX (syssts_t sts)
	Restores the specified execution status and leaves a critical zone. More...

bool	chSysIsCounterWithinX (rtcnt_t cnt, rtcnt_t start, rtcnt_t end)
	Realtime window test. More...

void	chSysPolledDelayX (rtcnt_t cycles)
	Polled delay. More...

thread_t *	chSchReadyI (thread_t *tp, msg_t msg)
	Makes the specified thread ready for execution. More...

bool	chSchIsPreemptionRequired (void)
	Evaluates if preemption is required. More...

void	chSchDoPreemption (void)
	Switches to the first thread on the runnable queue. More...

void	chSchRescheduleS (void)
	Reschedules if needed. More...

msg_t	chSchGoSleepTimeoutS (tstate_t newstate, sysinterval_t timeout)
	Puts the current thread to sleep into the specified state with timeout specification. More...

bool	chTimeIsInRangeX (systime_t time, systime_t start, systime_t end)
	Checks if the specified time is within the specified time range. More...

thread_t *	chThdCreateI (const thread_descriptor_t *tdp)
	Creates a new thread into a static memory area. More...

thread_t *	chThdCreate (const thread_descriptor_t *tdp)
	Creates a new thread into a static memory area. More...

void	chThdExit (msg_t msg)
	Terminates the current thread. More...

msg_t	chThdWait (thread_t *tp)
	Blocks the execution of the invoking thread until the specified thread terminates then the exit code is returned. More...

msg_t	chThdSuspendTimeoutS (thread_reference_t *trp, sysinterval_t timeout)
	Sends the current thread sleeping and sets a reference variable. More...

void	chThdResumeI (thread_reference_t *trp, msg_t msg)
	Wakes up a thread waiting on a thread reference object. More...

void	chThdResume (thread_reference_t *trp, msg_t msg)
	Wakes up a thread waiting on a thread reference object. More...

void	chThdSleep (sysinterval_t timeout)
	Suspends the invoking thread for the specified time. More...

void	chThdSleepUntil (systime_t abstime)
	Suspends the invoking thread until the system time arrives to the specified value. More...

msg_t	chThdEnqueueTimeoutS (threads_queue_t *tqp, sysinterval_t timeout)
	Enqueues the caller thread on a threads queue object. More...

void	chThdDoDequeueNextI (threads_queue_t *tqp, msg_t msg)
	Dequeues and wakes up one thread from the threads queue object. More...

void	chThdDequeueNextI (threads_queue_t *tqp, msg_t msg)
	Dequeues and wakes up one thread from the threads queue object, if any. More...

void	chThdDequeueAllI (threads_queue_t *tqp, msg_t msg)
	Dequeues and wakes up all threads from the threads queue object. More...

Variables
os_instance_t	nil
	System data structures. More...

Macro Definition Documentation

◆ __CHIBIOS_NIL__

#define __CHIBIOS_NIL__

ChibiOS/NIL identification macro.

Definition at line 42 of file nil/include/ch.h.

◆ CH_KERNEL_STABLE

#define CH_KERNEL_STABLE 0

Stable release flag.

Definition at line 47 of file nil/include/ch.h.

◆ CH_KERNEL_VERSION

#define CH_KERNEL_VERSION "4.1.0"

Kernel version string.

Definition at line 56 of file nil/include/ch.h.

◆ CH_KERNEL_MAJOR

#define CH_KERNEL_MAJOR 4

Kernel version major number.

Definition at line 61 of file nil/include/ch.h.

◆ CH_KERNEL_MINOR

#define CH_KERNEL_MINOR 1

Kernel version minor number.

Definition at line 66 of file nil/include/ch.h.

◆ CH_KERNEL_PATCH

#define CH_KERNEL_PATCH 0

Kernel version patch number.

Definition at line 71 of file nil/include/ch.h.

◆ FALSE

#define FALSE 0

Generic 'false' preprocessor boolean constant.

Note: It is meant to be used in configuration files as switch.

Definition at line 83 of file nil/include/ch.h.

◆ TRUE

#define TRUE 1

Generic 'true' preprocessor boolean constant.

Note: It is meant to be used in configuration files as switch.

Definition at line 91 of file nil/include/ch.h.

◆ MSG_OK

#define MSG_OK (msg_t)0

OK wakeup message.

Definition at line 99 of file nil/include/ch.h.

◆ MSG_TIMEOUT

#define MSG_TIMEOUT (msg_t)-1

Wake-up caused by a timeout condition.

Definition at line 100 of file nil/include/ch.h.

◆ MSG_RESET

#define MSG_RESET (msg_t)-2

Wake-up caused by a reset condition.

Definition at line 102 of file nil/include/ch.h.

◆ TIME_IMMEDIATE

#define TIME_IMMEDIATE ((sysinterval_t)-1)

Zero time specification for some functions with a timeout specification.

Note: Not all functions accept TIME_IMMEDIATE as timeout parameter, see the specific function documentation.

Definition at line 116 of file nil/include/ch.h.

◆ TIME_INFINITE

#define TIME_INFINITE ((sysinterval_t)0)

Infinite time specification for all functions with a timeout specification.

Definition at line 122 of file nil/include/ch.h.

◆ TIME_MAX_INTERVAL

#define TIME_MAX_INTERVAL ((sysinterval_t)-2)

Maximum interval constant usable as timeout.

Definition at line 127 of file nil/include/ch.h.

◆ TIME_MAX_SYSTIME

#define TIME_MAX_SYSTIME ((systime_t)-1)

Maximum system of system time before it wraps.

Definition at line 132 of file nil/include/ch.h.

◆ NIL_STATE_WTSTART

#define NIL_STATE_WTSTART (tstate_t)0

Thread not yet started or terminated.

Definition at line 139 of file nil/include/ch.h.

◆ NIL_STATE_READY

#define NIL_STATE_READY (tstate_t)1

Thread ready or executing.

Definition at line 141 of file nil/include/ch.h.

◆ NIL_STATE_SLEEPING

#define NIL_STATE_SLEEPING (tstate_t)2

Thread sleeping.

Definition at line 143 of file nil/include/ch.h.

◆ NIL_STATE_SUSPENDED

#define NIL_STATE_SUSPENDED (tstate_t)3

Thread suspended.

Definition at line 144 of file nil/include/ch.h.

◆ NIL_STATE_WTEXIT

#define NIL_STATE_WTEXIT (tstate_t)4

Waiting a thread.

Definition at line 145 of file nil/include/ch.h.

◆ NIL_STATE_WTQUEUE

#define NIL_STATE_WTQUEUE (tstate_t)5

On queue or semaph.

Definition at line 146 of file nil/include/ch.h.

◆ NIL_STATE_WTOREVT

#define NIL_STATE_WTOREVT (tstate_t)6

Waiting for events.

Definition at line 147 of file nil/include/ch.h.

◆ NIL_STATE_WTANDEVT

#define NIL_STATE_WTANDEVT (tstate_t)7

Waiting for events.

Definition at line 148 of file nil/include/ch.h.

◆ NIL_STATE_SNDMSGQ

#define NIL_STATE_SNDMSGQ (tstate_t)8

Sending a message, in queue.

Definition at line 149 of file nil/include/ch.h.

◆ NIL_STATE_WTMSG

#define NIL_STATE_WTMSG (tstate_t)10

Waiting for a message.

Definition at line 151 of file nil/include/ch.h.

◆ NIL_STATE_FINAL

#define NIL_STATE_FINAL (tstate_t)11

Thread terminated.

Definition at line 153 of file nil/include/ch.h.

◆ THD_IDLE_BASE

#define THD_IDLE_BASE (&__main_thread_stack_base__)

Boundaries of the idle thread boundaries, only required if stack checking is enabled.

Definition at line 370 of file nil/include/ch.h.

◆ __CH_STRINGIFY

#define __CH_STRINGIFY ( a ) #a

Utility to make the parameter a quoted string.

Definition at line 618 of file nil/include/ch.h.

◆ THD_TABLE_BEGIN

#define THD_TABLE_BEGIN const thread_descriptor_t nil_thd_configs[] = {

Start of user threads table.

Definition at line 627 of file nil/include/ch.h.

◆ THD_TABLE_THREAD

#define THD_TABLE_THREAD	(	_prio,
		_name,
		_wap,
		_funcp,
		_arg
	)

Value:

  {                                                                         \
    .name  = (_name),                                                       \
    .wbase = (_wap),                                                        \
    .wend  = THD_WORKING_AREA_END(_wap),                                    \
    .prio  = (_prio),                                                       \
    .funcp = (_funcp),                                                      \
    .arg   = (_arg)                                                         \
  },

Entry of user threads table.

Definition at line 633 of file nil/include/ch.h.

◆ THD_TABLE_END

#define THD_TABLE_END

Value:

  {                                                                         \
    .name  = "idle",                                                        \
    .wbase = THD_IDLE_BASE,                                                 \
    .wend  = THD_IDLE_END,                                                  \
    .prio  = CH_CFG_MAX_THREADS,                                            \
    .funcp = NULL,                                                          \
    .arg  = NULL                                                            \
  }                                                                         \
};

End of user threads table.

Definition at line 646 of file nil/include/ch.h.

◆ MEM_ALIGN_MASK

#define MEM_ALIGN_MASK ( a ) ((size_t)(a) - 1U)

Alignment mask constant.

Parameters

[in] a alignment, must be a power of two

Definition at line 667 of file nil/include/ch.h.

◆ MEM_ALIGN_PREV

#define MEM_ALIGN_PREV	(	p,
		a
	)	((size_t)(p) & ~MEM_ALIGN_MASK(a))

Aligns to the previous aligned memory address.

Parameters

[in]	p	variable to be aligned
[in]	a	alignment, must be a power of two

Definition at line 675 of file nil/include/ch.h.

◆ MEM_ALIGN_NEXT

#define MEM_ALIGN_NEXT	(	p,
		a
	)

Value:

MEM_ALIGN_PREV((size_t)(p) + \

MEM_ALIGN_MASK(a), (a))

Aligns to the new aligned memory address.

Parameters

[in]	p	variable to be aligned
[in]	a	alignment, must be a power of two

Definition at line 683 of file nil/include/ch.h.

◆ MEM_IS_ALIGNED

#define MEM_IS_ALIGNED	(	p,
		a
	)	(((size_t)(p) & MEM_ALIGN_MASK(a)) == 0U)

Returns whatever a pointer or memory size is aligned.

Parameters

[in]	p	variable to be aligned
[in]	a	alignment, must be a power of two

Definition at line 692 of file nil/include/ch.h.

◆ MEM_IS_VALID_ALIGNMENT

#define MEM_IS_VALID_ALIGNMENT ( a ) (((size_t)(a) != 0U) && (((size_t)(a) & ((size_t)(a) - 1U)) == 0U))

Returns whatever a constant is a valid alignment.

Valid alignments are powers of two.

Parameters

[in] a alignment to be checked, must be a constant

Definition at line 700 of file nil/include/ch.h.

◆ THD_WORKING_AREA_SIZE

#define THD_WORKING_AREA_SIZE ( n )

Value:

MEM_ALIGN_NEXT(PORT_WA_SIZE(n), \

PORT_STACK_ALIGN)

Calculates the total Working Area size.

Parameters

[in] n the stack size to be assigned to the thread

Returns: The total used memory in bytes.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 716 of file nil/include/ch.h.

◆ THD_WORKING_AREA

#define THD_WORKING_AREA	(	s,
		n
	)	PORT_WORKING_AREA(s, n)

Static working area allocation.

This macro is used to allocate a static thread working area aligned as both position and size.

Parameters

[in]	s	the name to be assigned to the stack array
[in]	n	the stack size to be assigned to the thread

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 729 of file nil/include/ch.h.

◆ THD_WORKING_AREA_END

#define THD_WORKING_AREA_END ( wa ) ((wa) + ((sizeof wa) / sizeof (stkalign_t)))

Returns the top address of a working area.

Note: The parameter is assumed to be an array of stkalign_t. The macros is invalid for anything else.

Parameters

[in] wa working area array

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 741 of file nil/include/ch.h.

◆ THD_FUNCTION

#define THD_FUNCTION	(	tname,
		arg
	)	PORT_THD_FUNCTION(tname, arg)

Thread declaration macro.

Note: Thread declarations should be performed using this macro because the port layer could define optimizations for thread functions.

Definition at line 753 of file nil/include/ch.h.

◆ CH_IRQ_IS_VALID_PRIORITY

#define CH_IRQ_IS_VALID_PRIORITY ( prio ) PORT_IRQ_IS_VALID_PRIORITY(prio)

Priority level validation macro.

This macro determines if the passed value is a valid priority level for the underlying architecture.

Parameters

[in] prio the priority level

Returns: Priority range result.

Return values

false	if the priority is invalid or if the architecture does not support priorities.
true	if the priority is valid.

Definition at line 772 of file nil/include/ch.h.

◆ CH_IRQ_IS_VALID_KERNEL_PRIORITY

#define CH_IRQ_IS_VALID_KERNEL_PRIORITY ( prio ) PORT_IRQ_IS_VALID_KERNEL_PRIORITY(prio)

Priority level validation macro.

This macro determines if the passed value is a valid priority level that cannot preempt the kernel critical zone.

Parameters

[in] prio the priority level

Returns: Priority range result.

Return values

false	if the priority is invalid or if the architecture does not support priorities.
true	if the priority is valid.

Definition at line 790 of file nil/include/ch.h.

◆ CH_IRQ_PROLOGUE

#define CH_IRQ_PROLOGUE ( )

Value:

PORT_IRQ_PROLOGUE(); \

__dbg_check_enter_isr()

IRQ handler enter code.

Note: Usually IRQ handlers functions are also declared naked.; On some architectures this macro can be empty.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 803 of file nil/include/ch.h.

◆ CH_IRQ_EPILOGUE

#define CH_IRQ_EPILOGUE ( )

Value:

__dbg_check_leave_isr(); \

PORT_IRQ_EPILOGUE()

IRQ handler exit code.

Note: Usually IRQ handlers function are also declared naked.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 813 of file nil/include/ch.h.

◆ CH_IRQ_HANDLER

#define CH_IRQ_HANDLER ( id ) PORT_IRQ_HANDLER(id)

Standard normal IRQ handler declaration.

Note: id can be a function name or a vector number depending on the port implementation.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 824 of file nil/include/ch.h.

◆ CH_FAST_IRQ_HANDLER

#define CH_FAST_IRQ_HANDLER ( id ) PORT_FAST_IRQ_HANDLER(id)

Standard fast IRQ handler declaration.

Note: id can be a function name or a vector number depending on the port implementation.; Not all architectures support fast interrupts.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 839 of file nil/include/ch.h.

◆ TIME_S2I

#define TIME_S2I ( secs ) ((sysinterval_t)((time_conv_t)(secs) * (time_conv_t)CH_CFG_ST_FREQUENCY))

Seconds to time interval.

Converts from seconds to system ticks number.

Note: The result is rounded upward to the next tick boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] secs number of seconds

Returns: The number of ticks.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 859 of file nil/include/ch.h.

◆ TIME_MS2I

#define TIME_MS2I ( msecs )

Value:

  ((sysinterval_t)((((time_conv_t)(msecs) *                                 \
                     (time_conv_t)CH_CFG_ST_FREQUENCY) +                    \
                    (time_conv_t)999) / (time_conv_t)1000))

Milliseconds to time interval.

Converts from milliseconds to system ticks number.

Note: The result is rounded upward to the next tick boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] msecs number of milliseconds

Returns: The number of ticks.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 875 of file nil/include/ch.h.

◆ TIME_US2I

#define TIME_US2I ( usecs )

Value:

  ((sysinterval_t)((((time_conv_t)(usecs) *                                 \
                     (time_conv_t)CH_CFG_ST_FREQUENCY) +                    \
                    (time_conv_t)999999) / (time_conv_t)1000000))

Microseconds to time interval.

Converts from microseconds to system ticks number.

Note: The result is rounded upward to the next tick boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] usecs number of microseconds

Returns: The number of ticks.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 893 of file nil/include/ch.h.

◆ TIME_I2S

#define TIME_I2S ( interval )

Value:

  (time_secs_t)(((time_conv_t)(interval) +                                  \
                 (time_conv_t)CH_CFG_ST_FREQUENCY -                         \
                 (time_conv_t)1) / (time_conv_t)CH_CFG_ST_FREQUENCY)

Time interval to seconds.

Converts from system ticks number to seconds.

Note: The result is rounded up to the next second boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] interval interval in ticks

Returns: The number of seconds.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 911 of file nil/include/ch.h.

◆ TIME_I2MS

#define TIME_I2MS ( interval )

Value:

  (time_msecs_t)((((time_conv_t)(interval) * (time_conv_t)1000) +           \
                  (time_conv_t)CH_CFG_ST_FREQUENCY - (time_conv_t)1) /      \
                 (time_conv_t)CH_CFG_ST_FREQUENCY)

Time interval to milliseconds.

Converts from system ticks number to milliseconds.

Note: The result is rounded up to the next millisecond boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] interval interval in ticks

Returns: The number of milliseconds.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 929 of file nil/include/ch.h.

◆ TIME_I2US

#define TIME_I2US ( interval )

Value:

    (time_msecs_t)((((time_conv_t)(interval) * (time_conv_t)1000000) +      \
                    (time_conv_t)CH_CFG_ST_FREQUENCY - (time_conv_t)1) /    \
                   (time_conv_t)CH_CFG_ST_FREQUENCY)

Time interval to microseconds.

Converts from system ticks number to microseconds.

Note: The result is rounded up to the next microsecond boundary.; Use of this macro for large values is not secure because integer overflows, make sure your value can be correctly converted.

Parameters

[in] interval interval in ticks

Returns: The number of microseconds.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 947 of file nil/include/ch.h.

◆ __THREADS_QUEUE_DATA

#define __THREADS_QUEUE_DATA ( name ) {(cnt_t)0}

Data part of a static threads queue object initializer.

This macro should be used when statically initializing a threads queue that is part of a bigger structure.

Parameters

[in] name the name of the threads queue variable

Definition at line 964 of file nil/include/ch.h.

◆ THREADS_QUEUE_DECL

#define THREADS_QUEUE_DECL ( name ) threads_queue_t name = __THREADS_QUEUE_DATA(name)

Static threads queue object initializer.

Statically initialized threads queues require no explicit initialization using queue_init().

Parameters

[in] name the name of the threads queue variable

Definition at line 973 of file nil/include/ch.h.

◆ chSysGetRealtimeCounterX

#define chSysGetRealtimeCounterX ( ) (rtcnt_t)port_rt_get_counter_value()

Returns the current value of the system real time counter.

Note: This function is only available if the port layer supports the option PORT_SUPPORTS_RT.

Returns: The value of the system realtime counter of type rtcnt_t.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 992 of file nil/include/ch.h.

◆ chSysDisable

#define chSysDisable ( )

Value:

  {                                                    \
  port_disable();                                                           \
  __dbg_check_disable();                                                    \
}

Raises the system interrupt priority mask to the maximum level.

All the maskable interrupt sources are disabled regardless their hardware priority.

Note: Do not invoke this API from within a kernel lock.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1003 of file nil/include/ch.h.

◆ chSysSuspend

#define chSysSuspend ( )

Value:

  {                                                    \
  port_suspend();                                                           \
  __dbg_check_suspend();                                                    \
}

Raises the system interrupt priority mask to system level.

The interrupt sources that should not be able to preempt the kernel are disabled, interrupt sources with higher priority are still enabled.

Note: Do not invoke this API from within a kernel lock.; This API is no replacement for chSysLock(), the chSysLock() could do more than just disable the interrupts.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1019 of file nil/include/ch.h.

◆ chSysEnable

#define chSysEnable ( )

Value:

  {                                                     \
  __dbg_check_enable();                                                     \
  port_enable();                                                            \
}

Lowers the system interrupt priority mask to user level.

All the interrupt sources are enabled.

Note: Do not invoke this API from within a kernel lock.; This API is no replacement for chSysUnlock(), the chSysUnlock() could do more than just enable the interrupts.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1033 of file nil/include/ch.h.

◆ chSysLock

#define chSysLock ( )

Value:

  {                                                       \
  port_lock();                                                              \
  __dbg_check_lock();                                                       \
}

Enters the kernel lock state.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1043 of file nil/include/ch.h.

◆ chSysUnlock

#define chSysUnlock ( )

Value:

  {                                                     \
  __dbg_check_unlock();                                                     \
  port_unlock();                                                            \
}

Leaves the kernel lock state.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1053 of file nil/include/ch.h.

◆ chSysLockFromISR

#define chSysLockFromISR ( )

Value:

  {                                                \
  port_lock_from_isr();                                                     \
  __dbg_check_lock_from_isr();                                              \
}

Enters the kernel lock state from within an interrupt handler.

Note: This API may do nothing on some architectures, it is required because on ports that support preemptable interrupt handlers it is required to raise the interrupt mask to the same level of the system mutual exclusion zone.
It is good practice to invoke this API before invoking any I-class syscall from an interrupt handler.; This API must be invoked exclusively from interrupt handlers.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1070 of file nil/include/ch.h.

◆ chSysUnlockFromISR

#define chSysUnlockFromISR ( )

Value:

  {                                              \
  __dbg_check_unlock_from_isr();                                            \
  port_unlock_from_isr();                                                   \
}

Leaves the kernel lock state from within an interrupt handler.

Note: This API may do nothing on some architectures, it is required because on ports that support preemptable interrupt handlers it is required to raise the interrupt mask to the same level of the system mutual exclusion zone.
It is good practice to invoke this API after invoking any I-class syscall from an interrupt handler.; This API must be invoked exclusively from interrupt handlers.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 1088 of file nil/include/ch.h.

◆ chSchGoSleepS

#define chSchGoSleepS ( newstate ) chSchGoSleepTimeoutS(newstate, TIME_INFINITE)

Puts the current thread to sleep into the specified state.

Parameters

[in] newstate the new thread state or a semaphore pointer

Returns: The wakeup message.

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1101 of file nil/include/ch.h.

◆ chSchWakeupS

#define chSchWakeupS	(	ntp,
		msg
	)

Value:

  do {                                         \
  chSchReadyI(ntp, msg);                                                    \
  chSchRescheduleS();                                                       \
} while (false)

Wakes up a thread.

Parameters

[in]	ntp	the thread to be made ready
[in]	msg	the wakeup message

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1111 of file nil/include/ch.h.

◆ chSchIsRescRequiredI

#define chSchIsRescRequiredI ( ) ((bool)(nil.current != nil.next))

Evaluates if a reschedule is required.

Return values

true	if there is a thread that must go in running state immediately.
false	if preemption is not required.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 1125 of file nil/include/ch.h.

◆ chThdGetSelfX

#define chThdGetSelfX ( ) nil.current

Returns a pointer to the current thread_t.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1132 of file nil/include/ch.h.

◆ chThdGetPriorityX

#define chThdGetPriorityX ( void ) (tprio_t)(nil.current - &nil.threads[0])

Returns the current thread priority.

Note: Can be invoked in any context.

Returns: The current thread priority.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1142 of file nil/include/ch.h.

◆ chThdResumeS

#define chThdResumeS	(	trp,
		msg
	)

Value:

  do {                                         \
  chThdResumeI(trp, msg);                                                   \
  chSchRescheduleS();                                                       \
} while (false)

Wakes up a thread waiting on a thread reference object.

Note: This function must reschedule, it can only be called from thread context.

Parameters

[in]	trp	a pointer to a thread reference object
[in]	msg	the message code

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1154 of file nil/include/ch.h.

◆ chThdSleepSeconds

#define chThdSleepSeconds ( secs ) chThdSleep(TIME_S2I(secs))

Delays the invoking thread for the specified number of seconds.

Note: The specified time is rounded up to a value allowed by the real system clock.; The maximum specified value is implementation dependent.

Parameters

[in] secs time in seconds, must be different from zero

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 1169 of file nil/include/ch.h.

◆ chThdSleepMilliseconds

#define chThdSleepMilliseconds ( msecs ) chThdSleep(TIME_MS2I(msecs))

Delays the invoking thread for the specified number of milliseconds.

Note: The specified time is rounded up to a value allowed by the real system clock.; The maximum specified value is implementation dependent.

Parameters

[in] msecs time in milliseconds, must be different from zero

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 1182 of file nil/include/ch.h.

◆ chThdSleepMicroseconds

#define chThdSleepMicroseconds ( usecs ) chThdSleep(TIME_US2I(usecs))

Delays the invoking thread for the specified number of microseconds.

Note: The specified time is rounded up to a value allowed by the real system clock.; The maximum specified value is implementation dependent.

Parameters

[in] usecs time in microseconds, must be different from zero

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 1195 of file nil/include/ch.h.

◆ chThdSleepS

#define chThdSleepS ( timeout ) (void) chSchGoSleepTimeoutS(NIL_STATE_SLEEPING, timeout)

Suspends the invoking thread for the specified time.

Parameters

[in] timeout the delay in system ticks

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1204 of file nil/include/ch.h.

◆ chThdSleepUntilS

#define chThdSleepUntilS ( abstime )

Value:

(void) chSchGoSleepTimeoutS(NIL_STATE_SLEEPING, \

chTimeDiffX(chVTGetSystemTimeX(), (abstime)))

Suspends the invoking thread until the system time arrives to the specified value.

Parameters

[in] abstime absolute system time

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1215 of file nil/include/ch.h.

◆ chThdQueueObjectInit

#define chThdQueueObjectInit ( tqp ) ((tqp)->cnt = (cnt_t)0)

Initializes a threads queue object.

Parameters

[out] tqp pointer to the threads queue object

Function Class:: Initializer, this function just initializes an object and can be invoked before the kernel is initialized.

Definition at line 1226 of file nil/include/ch.h.

◆ chThdQueueIsEmptyI

#define chThdQueueIsEmptyI ( tqp ) ((bool)(tqp->cnt >= (cnt_t)0))

Evaluates to true if the specified queue is empty.

Parameters

[out] tqp pointer to the threads queue object

Returns: The queue status.

Return values

false	if the queue is not empty.
true	if the queue is empty.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 1238 of file nil/include/ch.h.

◆ chVTGetSystemTimeX

#define chVTGetSystemTimeX ( ) (nil.systime)

Current system time.

Returns the number of system ticks since the chSysInit() invocation.

Note: The counter can reach its maximum and then restart from zero.; This function can be called from any context but its atomicity is not guaranteed on architectures whose word size is less than systime_t size.

Returns: The system time in ticks.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1254 of file nil/include/ch.h.

◆ chVTTimeElapsedSinceX

#define chVTTimeElapsedSinceX ( start ) chTimeDiffX((start), chVTGetSystemTimeX())

Returns the elapsed time since the specified start time.

Parameters

[in] start start time

Returns: The elapsed time.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1267 of file nil/include/ch.h.

◆ chVTIsSystemTimeWithinX

#define chVTIsSystemTimeWithinX	(	start,
		end
	)	chTimeIsInRangeX(chVTGetSystemTimeX(), start, end)

Checks if the current system time is within the specified time window.

Note: When start==end then the function returns always false because the time window has zero size.

Parameters

[in]	start	the start of the time window (inclusive)
[in]	end	the end of the time window (non inclusive)

Return values

true	current time within the specified time window.
false	current time not within the specified time window.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1283 of file nil/include/ch.h.

◆ chTimeAddX

#define chTimeAddX	(	systime,
		interval
	)	((systime_t)(systime) + (systime_t)(interval))

Adds an interval to a system time returning a system time.

Parameters

[in]	systime	base system time
[in]	interval	interval to be added

Returns: The new system time.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1295 of file nil/include/ch.h.

◆ chTimeDiffX

#define chTimeDiffX	(	start,
		end
	)	((sysinterval_t)((systime_t)((systime_t)(end) - (systime_t)(start))))

Subtracts two system times returning an interval.

Parameters

[in]	start	first system time
[in]	end	second system time

Returns: The interval representing the time difference.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 1307 of file nil/include/ch.h.

◆ chDbgCheck

#define chDbgCheck ( c )

Value:

  do {                                                  \
  /*lint -save -e506 -e774 [2.1, 14.3] Can be a constant by design.*/       \
  if (CH_DBG_ENABLE_CHECKS != FALSE) {                                      \
    if (!(c)) {                                                             \
  /*lint -restore*/                                                         \
      chSysHalt(__func__);                                                  \
    }                                                                       \
  }                                                                         \
} while (false)

Function parameters check.

If the condition check fails then the kernel panics and halts.

Note: The condition is tested only if the CH_DBG_ENABLE_CHECKS switch is specified in chconf.h else the macro does nothing.

Parameters

[in] c the condition to be verified to be true

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 1321 of file nil/include/ch.h.

◆ chDbgAssert

#define chDbgAssert	(	c,
		r
	)

Value:

  do {                                              \
  /*lint -save -e506 -e774 [2.1, 14.3] Can be a constant by design.*/       \
  if (CH_DBG_ENABLE_ASSERTS != FALSE) {                                     \
    if (!(c)) {                                                             \
  /*lint -restore*/                                                         \
      chSysHalt(__func__);                                                  \
    }                                                                       \
  }                                                                         \
} while (false)

Condition assertion.

If the condition check fails then the kernel panics with a message and halts.

Note: The condition is tested only if the CH_DBG_ENABLE_ASSERTS switch is specified in chconf.h else the macro does nothing.; The remark string is not currently used except for putting a comment in the code about the assertion.

Parameters

[in]	c	the condition to be verified to be true
[in]	r	a remark string

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 1347 of file nil/include/ch.h.

Typedef Documentation

◆ rtcnt_t

typedef port_rtcnt_t rtcnt_t

Realtime counter.

Definition at line 386 of file nil/include/ch.h.

◆ syssts_t

typedef port_syssts_t syssts_t

System status word.

Definition at line 387 of file nil/include/ch.h.

◆ stkalign_t

typedef port_stkalign_t stkalign_t

Stack alignment type.

Definition at line 388 of file nil/include/ch.h.

◆ tstate_t

typedef uint8_t tstate_t

Thread state.

Definition at line 391 of file nil/include/ch.h.

◆ tprio_t

typedef uint32_t tprio_t

Thread priority.

Definition at line 392 of file nil/include/ch.h.

◆ msg_t

typedef int32_t msg_t

Inter-thread message.

Definition at line 393 of file nil/include/ch.h.

◆ eventid_t

typedef int32_t eventid_t

Numeric event identifier.

Definition at line 394 of file nil/include/ch.h.

◆ eventmask_t

typedef uint32_t eventmask_t

Mask of event identifiers.

Definition at line 395 of file nil/include/ch.h.

◆ eventflags_t

typedef uint32_t eventflags_t

Mask of event flags.

Definition at line 396 of file nil/include/ch.h.

◆ cnt_t

typedef int32_t cnt_t

Generic signed counter.

Definition at line 397 of file nil/include/ch.h.

◆ ucnt_t

typedef uint32_t ucnt_t

Generic unsigned counter.

Definition at line 398 of file nil/include/ch.h.

◆ systime_t

typedef uint32_t systime_t

Type of system time.

Note: It is selectable in configuration between 16 or 32 bits.

Definition at line 428 of file nil/include/ch.h.

◆ sysinterval_t

typedef uint32_t sysinterval_t

Type of time interval.

Note: It is selectable in configuration between 16 or 32 bits.

Definition at line 434 of file nil/include/ch.h.

◆ time_conv_t

typedef uint64_t time_conv_t

Type of time conversion variable.

Note: This type must have double width than other time types, it is only used internally for conversions.

Definition at line 441 of file nil/include/ch.h.

◆ os_instance_t

typedef struct nil_os_instance os_instance_t

Type of a structure representing the system.

Definition at line 452 of file nil/include/ch.h.

◆ tfunc_t

typedef void(* tfunc_t) (void *p)

Thread function.

Definition at line 457 of file nil/include/ch.h.

◆ thread_descriptor_t

typedef struct nil_thread_descriptor thread_descriptor_t

Type of a thread descriptor.

Definition at line 462 of file nil/include/ch.h.

◆ thread_t

typedef struct nil_thread thread_t

Type of a structure representing a thread.

Note: It is required as an early definition.

Definition at line 468 of file nil/include/ch.h.

◆ thread_reference_t

typedef thread_t* thread_reference_t

Type of a thread reference.

Definition at line 473 of file nil/include/ch.h.

◆ threads_queue_t

typedef struct nil_threads_queue threads_queue_t

Type of a queue of threads.

Definition at line 478 of file nil/include/ch.h.

◆ semaphore_t

typedef threads_queue_t semaphore_t

Type of a structure representing a semaphore.

Note: Semaphores are implemented on thread queues, the object is the same, the behavior is slightly different.

Definition at line 486 of file nil/include/ch.h.

Function Documentation

◆ nil_find_thread()

thread_t * nil_find_thread	(	tstate_t	state,
		void *	p
	)

Retrieves the highest priority thread in the specified state and associated to the specified object.

Parameters

[in]	state	thread state
[in]	p	object pointer

Returns: The pointer to the found thread.

Return values

NULL	if the thread is not found.

Function Class:: Not an API, this function is for internal use only.

Definition at line 70 of file ch.c.

References CH_CFG_MAX_THREADS, nil, and ch_thread::state.

Referenced by chThdDoDequeueNextI().

◆ nil_ready_all()

cnt_t nil_ready_all	(	void *	p,
		cnt_t	cnt,
		msg_t	msg
	)

Puts in ready state all thread matching the specified status and associated object.

Parameters

[in]	p	object pointer
[in]	cnt	number of threads to be readied as a negative number, non negative numbers are ignored
[in]	msg	the wakeup message

Returns: The number of readied threads.

Function Class:: Not an API, this function is for internal use only.

Definition at line 95 of file ch.c.

References CH_CFG_MAX_THREADS, chDbgAssert, chSchReadyI(), nil, NIL_STATE_WTQUEUE, and ch_thread::state.

Referenced by chThdDequeueAllI().

Here is the call graph for this function:

◆ __dbg_check_disable()

void __dbg_check_disable ( void )

Guard code for chSysDisable().

Function Class:: Not an API, this function is for internal use only.

Definition at line 120 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_suspend()

void __dbg_check_suspend ( void )

Guard code for chSysSuspend().

Function Class:: Not an API, this function is for internal use only.

Definition at line 132 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_enable()

void __dbg_check_enable ( void )

Guard code for chSysEnable().

Function Class:: Not an API, this function is for internal use only.

Definition at line 144 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_lock()

void __dbg_check_lock ( void )

Guard code for chSysLock().

Function Class:: Not an API, this function is for internal use only.

Definition at line 156 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_unlock()

void __dbg_check_unlock ( void )

Guard code for chSysUnlock().

Function Class:: Not an API, this function is for internal use only.

Definition at line 169 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_lock_from_isr()

void __dbg_check_lock_from_isr ( void )

Guard code for chSysLockFromIsr().

Function Class:: Not an API, this function is for internal use only.

Definition at line 182 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_unlock_from_isr()

void __dbg_check_unlock_from_isr ( void )

Guard code for chSysUnlockFromIsr().

Function Class:: Not an API, this function is for internal use only.

Definition at line 195 of file ch.c.

References chSysHalt(), and nil.

Here is the call graph for this function:

◆ __dbg_check_enter_isr()

void __dbg_check_enter_isr ( void )

Guard code for CH_IRQ_PROLOGUE().

Function Class:: Not an API, this function is for internal use only.

Definition at line 208 of file ch.c.

References chSysHalt(), nil, port_lock_from_isr(), and port_unlock_from_isr().

Here is the call graph for this function:

◆ __dbg_check_leave_isr()

void __dbg_check_leave_isr ( void )

Guard code for CH_IRQ_EPILOGUE().

Function Class:: Not an API, this function is for internal use only.

Definition at line 223 of file ch.c.

References chSysHalt(), nil, port_lock_from_isr(), and port_unlock_from_isr().

Here is the call graph for this function:

◆ chDbgCheckClassI()

void chDbgCheckClassI ( void )

I-class functions context check.

Verifies that the system is in an appropriate state for invoking an I-class API function. A panic is generated if the state is not compatible.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 241 of file ch.c.

References chSysHalt(), and nil.

Referenced by chSchReadyI(), chSysTimerHandlerI(), chThdCreateI(), chThdDequeueAllI(), and chThdDequeueNextI().

Here is the call graph for this function:

◆ chDbgCheckClassS()

void chDbgCheckClassS ( void )

S-class functions context check.

Verifies that the system is in an appropriate state for invoking an S-class API function. A panic is generated if the state is not compatible.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 256 of file ch.c.

References chSysHalt(), and nil.

Referenced by chSchGoSleepTimeoutS(), chSchRescheduleS(), and chThdEnqueueTimeoutS().

Here is the call graph for this function:

◆ chSysInit()

void chSysInit ( void )

Initializes the kernel.

Initializes the kernel structures, the current instructions flow becomes the idle thread upon return. The idle thread must not invoke any kernel primitive able to change state to not runnable.

Note: This function assumes that the nil global variable has been zeroed by the runtime environment. If this is not the case then make sure to clear it before calling this function.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 275 of file ch.c.

References __oslib_init(), CH_CFG_MAX_THREADS, CH_CFG_SYSTEM_INIT_HOOK, chSchRescheduleS(), chSysSuspend, chSysUnlock, chThdCreateI(), thread_descriptor_t::funcp, nil, NIL_STATE_READY, and THD_IDLE_BASE.

Here is the call graph for this function:

◆ chSysHalt()

void chSysHalt ( const char * reason )

Halts the system.

This function is invoked by the operating system when an unrecoverable error is detected, for example because a programming error in the application code that triggers an assertion while in debug mode.

Note: Can be invoked from any system state.

Parameters

[in] reason pointer to an error string

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 330 of file ch.c.

References __trace_halt(), CH_CFG_SYSTEM_HALT_HOOK, currcore, nil, port_disable(), and ch_system::state.

Referenced by __dbg_check_disable(), __dbg_check_enable(), __dbg_check_enter_isr(), __dbg_check_leave_isr(), __dbg_check_lock(), __dbg_check_lock_from_isr(), __dbg_check_suspend(), __dbg_check_unlock(), __dbg_check_unlock_from_isr(), chDbgCheckClassI(), and chDbgCheckClassS().

Here is the call graph for this function:

◆ chSysTimerHandlerI()

void chSysTimerHandlerI ( void )

Time management handler.

Note: This handler has to be invoked by a periodic ISR in order to reschedule the waiting threads.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 355 of file ch.c.

References chDbgAssert, chDbgCheckClassI(), and nil.

Here is the call graph for this function:

◆ chSysUnconditionalLock()

void chSysUnconditionalLock ( void )

Unconditionally enters the kernel lock state.

Note: Can be called without previous knowledge of the current lock state. The final state is "s-locked".

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 458 of file ch.c.

References chSysLock, port_get_irq_status(), and port_irq_enabled().

Here is the call graph for this function:

◆ chSysUnconditionalUnlock()

void chSysUnconditionalUnlock ( void )

Unconditionally leaves the kernel lock state.

Note: Can be called without previous knowledge of the current lock state. The final state is "normal".

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 472 of file ch.c.

References chSysUnlock, port_get_irq_status(), and port_irq_enabled().

Here is the call graph for this function:

◆ chSysGetStatusAndLockX()

syssts_t chSysGetStatusAndLockX ( void )

Returns the execution status and enters a critical zone.

This functions enters into a critical zone and can be called from any context. Because its flexibility it is less efficient than chSysLock() which is preferable when the calling context is known.

Postcondition: The system is in a critical zone.

Returns: The previous system status, the encoding of this status word is architecture-dependent and opaque.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 492 of file ch.c.

References chSysLock, chSysLockFromISR, port_get_irq_status(), port_irq_enabled(), and port_is_isr_context().

Here is the call graph for this function:

◆ chSysRestoreStatusX()

void chSysRestoreStatusX ( syssts_t sts )

Restores the specified execution status and leaves a critical zone.

Note: A call to chSchRescheduleS() is automatically performed if exiting the critical zone and if not in ISR context.

Parameters

[in] sts the system status to be restored.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 515 of file ch.c.

References chSchRescheduleS(), chSysUnlock, chSysUnlockFromISR, port_irq_enabled(), and port_is_isr_context().

Here is the call graph for this function:

◆ chSysIsCounterWithinX()

bool chSysIsCounterWithinX	(	rtcnt_t	cnt,
		rtcnt_t	start,
		rtcnt_t	end
	)

Realtime window test.

This function verifies if the current realtime counter value lies within the specified range or not. The test takes care of the realtime counter wrapping to zero on overflow.

Note: When start==end then the function returns always false because a null time range is specified.; This function is only available if the port layer supports the option PORT_SUPPORTS_RT.

Parameters

[in]	cnt	the counter value to be tested
[in]	start	the start of the time window (inclusive)
[in]	end	the end of the time window (non inclusive)

Return values

true	current time within the specified time window.
false	current time not within the specified time window.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 547 of file ch.c.

Referenced by chSysPolledDelayX().

◆ chSysPolledDelayX()

void chSysPolledDelayX ( rtcnt_t cycles )

Polled delay.

Note: The real delay is always few cycles in excess of the specified value.; This function is only available if the port layer supports the option PORT_SUPPORTS_RT.

Parameters

[in] cycles number of cycles

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 564 of file ch.c.

References chSysGetRealtimeCounterX, and chSysIsCounterWithinX().

Here is the call graph for this function:

◆ chSchReadyI()

thread_t * chSchReadyI	(	thread_t *	tp,
		msg_t	msg
	)

Makes the specified thread ready for execution.

Parameters

[in]	tp	pointer to the `thread_t` object
[in]	msg	the wakeup message

Returns: The same reference passed as parameter.

Definition at line 581 of file ch.c.

References CH_CFG_MAX_THREADS, chDbgAssert, chDbgCheck, chDbgCheckClassI(), and nil.

Referenced by chThdDoDequeueNextI(), chThdExit(), and nil_ready_all().

Here is the call graph for this function:

◆ chSchIsPreemptionRequired()

bool chSchIsPreemptionRequired ( void )

Evaluates if preemption is required.

The decision is taken by comparing the relative priorities and depending on the state of the round robin timeout counter.

Note: Not a user function, it is meant to be invoked by the scheduler itself or from within the port layer.

Return values

true	if there is a thread that must go in running state immediately.
false	if preemption is not required.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 610 of file ch.c.

References chSchIsRescRequiredI.

◆ chSchDoPreemption()

void chSchDoPreemption ( void )

Switches to the first thread on the runnable queue.

Note: Not a user function, it is meant to be invoked by the scheduler itself or from within the port layer.

Function Class:: Special function, this function has special requirements see the notes.

Definition at line 622 of file ch.c.

References CH_CFG_IDLE_LEAVE_HOOK, CH_CFG_MAX_THREADS, nil, and port_switch.

Referenced by chSchRescheduleS().

◆ chSchRescheduleS()

void chSchRescheduleS ( void )

Reschedules if needed.

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 637 of file ch.c.

References chDbgCheckClassS(), chSchDoPreemption(), and chSchIsRescRequiredI.

Referenced by chSysInit(), chSysRestoreStatusX(), and chThdCreate().

Here is the call graph for this function:

◆ chSchGoSleepTimeoutS()

msg_t chSchGoSleepTimeoutS	(	tstate_t	newstate,
		sysinterval_t	timeout
	)

Puts the current thread to sleep into the specified state with timeout specification.

The thread goes into a sleeping state, if it is not awakened explicitly within the specified system time then it is forcibly awakened with a MSG_TIMEOUT low level message.

Parameters

[in]	newstate	the new thread state or a semaphore pointer
[in]	timeout	the number of ticks before the operation timeouts. the following special values are allowed: TIME_INFINITE no timeout.

Returns: The wakeup message.

Return values

MSG_TIMEOUT if a timeout occurred.

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 663 of file ch.c.

References CH_CFG_MAX_THREADS, chDbgAssert, chDbgCheckClassS(), nil, ch_thread::state, and TIME_INFINITE.

Referenced by chThdEnqueueTimeoutS(), chThdExit(), and chThdSuspendTimeoutS().

Here is the call graph for this function:

◆ chTimeIsInRangeX()

bool chTimeIsInRangeX	(	systime_t	time,
		systime_t	start,
		systime_t	end
	)

Checks if the specified time is within the specified time range.

Note: When start==end then the function returns always false because the time window has zero size.

Parameters

[in]	time	the time to be verified
[in]	start	the start of the time window (inclusive)
[in]	end	the end of the time window (non inclusive)

Return values

true	current time within the specified time window.
false	current time not within the specified time window.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 743 of file ch.c.

Referenced by chThdSleepUntilWindowed(), chVTIsSystemTimeWithin(), and chVTIsSystemTimeWithinX().

◆ chThdCreateI()

thread_t* chThdCreateI ( const thread_descriptor_t * tdp )

Creates a new thread into a static memory area.

The new thread is initialized and make ready to execute.

Note: A thread can terminate by calling chThdExit() or by simply returning from its main function.

Parameters

[out] tdp pointer to the thread descriptor structure

Returns: The pointer to the thread_t structure allocated for the thread.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 761 of file ch.c.

References CH_CFG_MAX_THREADS, chDbgAssert, chDbgCheck, chDbgCheckClassI(), thread_descriptor_t::funcp, MEM_IS_ALIGNED, nil, PORT_STACK_ALIGN, PORT_WORKING_AREA_ALIGN, thread_descriptor_t::prio, thread_descriptor_t::wbase, and thread_descriptor_t::wend.

Referenced by chSysInit(), and chThdCreate().

Here is the call graph for this function:

◆ chThdCreate()

thread_t* chThdCreate ( const thread_descriptor_t * tdp )

Creates a new thread into a static memory area.

The new thread is initialized and make ready to execute.

Note: A thread can terminate by calling chThdExit() or by simply returning from its main function.

Parameters

[out] tdp pointer to the thread descriptor structure

Returns: The pointer to the thread_t structure allocated for the thread.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 807 of file ch.c.

References chSchRescheduleS(), chSysLock, chSysUnlock, and chThdCreateI().

Here is the call graph for this function:

◆ chThdExit()

void chThdExit ( msg_t msg )

Terminates the current thread.

The thread goes in the CH_STATE_FINAL state holding the specified exit status code, other threads can retrieve the exit status code by invoking the function chThdWait().

Postcondition: Exiting a non-static thread that does not have references (detached) causes the thread to remain in the registry. It can only be removed by performing a registry scan operation.; Eventual code after this function will never be executed, this function never returns. The compiler has no way to know this so do not assume that the compiler would remove the dead code.

Parameters

[in] msg thread exit code

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 835 of file ch.c.

References CH_CFG_MAX_THREADS, CH_CFG_THREAD_EXIT_HOOK, chDbgAssert, chSchGoSleepTimeoutS(), chSchReadyI(), chSysLock, nil, NIL_STATE_FINAL, NIL_STATE_WTEXIT, ch_thread::state, and TIME_INFINITE.

Here is the call graph for this function:

◆ chThdWait()

msg_t chThdWait ( thread_t * tp )

Blocks the execution of the invoking thread until the specified thread terminates then the exit code is returned.

Parameters

[in] tp pointer to the thread

Returns: The exit code from the terminated thread.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 873 of file ch.c.

References chSysLock.

◆ chThdSuspendTimeoutS()

msg_t chThdSuspendTimeoutS	(	thread_reference_t *	trp,
		sysinterval_t	timeout
	)

Sends the current thread sleeping and sets a reference variable.

Note: This function must reschedule, it can only be called from thread context.

Parameters

[in]	trp	a pointer to a thread reference object
[in]	timeout	the number of ticks before the operation timeouts, the following special values are allowed: TIME_IMMEDIATE immediate timeout. TIME_INFINITE no timeout.

Returns: The wake up message.

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 904 of file ch.c.

References chDbgAssert, chSchGoSleepTimeoutS(), MSG_TIMEOUT, nil, NIL_STATE_SUSPENDED, and TIME_IMMEDIATE.

Here is the call graph for this function:

◆ chThdResumeI()

void chThdResumeI	(	thread_reference_t *	trp,
		msg_t	msg
	)

Wakes up a thread waiting on a thread reference object.

Note: This function must not reschedule because it can be called from ISR context.

Parameters

[in]	trp	a pointer to a thread reference object
[in]	msg	the message code

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 927 of file ch.c.

References chDbgAssert.

◆ chThdResume()

void chThdResume	(	thread_reference_t *	trp,
		msg_t	msg
	)

Wakes up a thread waiting on a thread reference object.

Note: This function must reschedule, it can only be called from thread context.

Parameters

[in]	trp	a pointer to a thread reference object
[in]	msg	the message code

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 949 of file ch.c.

References chSysLock, chSysUnlock, and chThdResumeS().

Here is the call graph for this function:

◆ chThdSleep()

void chThdSleep ( sysinterval_t timeout )

Suspends the invoking thread for the specified time.

Parameters

[in] timeout the delay in system ticks

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 963 of file ch.c.

References chSysLock, chSysUnlock, and chThdSleepS.

◆ chThdSleepUntil()

void chThdSleepUntil ( systime_t abstime )

Suspends the invoking thread until the system time arrives to the specified value.

Parameters

[in] abstime absolute system time

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 978 of file ch.c.

References chSysLock, chSysUnlock, and chThdSleepUntilS.

◆ chThdEnqueueTimeoutS()

msg_t chThdEnqueueTimeoutS	(	threads_queue_t *	tqp,
		sysinterval_t	timeout
	)

Enqueues the caller thread on a threads queue object.

The caller thread is enqueued and put to sleep until it is dequeued or the specified timeouts expires.

Parameters

[in]	tqp	pointer to the threads queue object
[in]	timeout	the timeout in system ticks, the special values are handled as follow: TIME_IMMEDIATE immediate timeout. TIME_INFINITE no timeout.

Returns: The message from osalQueueWakeupOneI() or osalQueueWakeupAllI() functions.

Return values

MSG_TIMEOUT if the thread has not been dequeued within the specified timeout or if the function has been invoked with TIME_IMMEDIATE as timeout specification.

Function Class:: This is an S-Class API, this function can be invoked from within a system lock zone by threads only.

Definition at line 1005 of file ch.c.

References chDbgAssert, chDbgCheck, chDbgCheckClassS(), chSchGoSleepTimeoutS(), MSG_TIMEOUT, nil, NIL_STATE_WTQUEUE, and TIME_IMMEDIATE.

Here is the call graph for this function:

◆ chThdDoDequeueNextI()

void chThdDoDequeueNextI	(	threads_queue_t *	tqp,
		msg_t	msg
	)

Dequeues and wakes up one thread from the threads queue object.

Dequeues one thread from the queue without checking if the queue is empty.

Precondition: The queue must contain at least an object.

Parameters

[in]	tqp	pointer to the threads queue object
[in]	msg	the message code

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 1032 of file ch.c.

References chDbgAssert, chSchReadyI(), nil_find_thread(), and NIL_STATE_WTQUEUE.

Referenced by chThdDequeueAllI(), and chThdDequeueNextI().

Here is the call graph for this function:

◆ chThdDequeueNextI()

void chThdDequeueNextI	(	threads_queue_t *	tqp,
		msg_t	msg
	)

Dequeues and wakes up one thread from the threads queue object, if any.

Parameters

[in]	tqp	pointer to the threads queue object
[in]	msg	the message code

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 1054 of file ch.c.

References chDbgCheck, chDbgCheckClassI(), and chThdDoDequeueNextI().

Here is the call graph for this function:

◆ chThdDequeueAllI()

void chThdDequeueAllI	(	threads_queue_t *	tqp,
		msg_t	msg
	)

Dequeues and wakes up all threads from the threads queue object.

Parameters

[in]	tqp	pointer to the threads queue object
[in]	msg	the message code

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 1072 of file ch.c.

References chDbgCheck, chDbgCheckClassI(), and nil_ready_all().

Here is the call graph for this function:

Variable Documentation

◆ nil

os_instance_t nil

Detailed Description

Macros

ChibiOS/NIL version identification

Constants for configuration options

Wakeup messages

Special time constants

Thread state related macros

RT options not existing in NIL

Kernel types

Threads tables definition macros

Memory alignment support macros

Working Areas

Threads abstraction macros

ISRs abstraction macros

Fast ISRs abstraction macros

Time conversion utilities

Threads queues

Macro Functions

Typedefs

Data Structures

Functions

Variables

Macro Definition Documentation

◆ __CHIBIOS_NIL__

◆ CH_KERNEL_STABLE

◆ CH_KERNEL_VERSION

◆ CH_KERNEL_MAJOR

◆ CH_KERNEL_MINOR

◆ CH_KERNEL_PATCH

◆ FALSE

◆ TRUE

◆ MSG_OK

◆ MSG_TIMEOUT

◆ MSG_RESET

◆ TIME_IMMEDIATE

◆ TIME_INFINITE

◆ TIME_MAX_INTERVAL

◆ TIME_MAX_SYSTIME

◆ NIL_STATE_WTSTART

◆ NIL_STATE_READY

◆ NIL_STATE_SLEEPING

◆ NIL_STATE_SUSPENDED

◆ NIL_STATE_WTEXIT

◆ NIL_STATE_WTQUEUE

◆ NIL_STATE_WTOREVT

◆ NIL_STATE_WTANDEVT

◆ NIL_STATE_SNDMSGQ

◆ NIL_STATE_WTMSG

◆ NIL_STATE_FINAL

◆ THD_IDLE_BASE

◆ __CH_STRINGIFY

◆ THD_TABLE_BEGIN

◆ THD_TABLE_THREAD

◆ THD_TABLE_END

◆ MEM_ALIGN_MASK

◆ MEM_ALIGN_PREV

◆ MEM_ALIGN_NEXT

◆ MEM_IS_ALIGNED

◆ MEM_IS_VALID_ALIGNMENT

◆ THD_WORKING_AREA_SIZE

◆ THD_WORKING_AREA

◆ THD_WORKING_AREA_END

◆ THD_FUNCTION

◆ CH_IRQ_IS_VALID_PRIORITY

◆ CH_IRQ_IS_VALID_KERNEL_PRIORITY

◆ CH_IRQ_PROLOGUE

◆ CH_IRQ_EPILOGUE

◆ CH_IRQ_HANDLER

◆ CH_FAST_IRQ_HANDLER

◆ TIME_S2I

◆ TIME_MS2I

◆ TIME_US2I

◆ TIME_I2S

◆ TIME_I2MS

◆ TIME_I2US

◆ __THREADS_QUEUE_DATA

◆ THREADS_QUEUE_DECL

◆ chSysGetRealtimeCounterX

◆ chSysDisable

◆ chSysSuspend
