thread_descriptor_t Struct Reference
Type of a thread descriptor. More...
#include <chthreads.h>
Collaboration diagram for thread_descriptor_t:
Data Fields | |
| const char * | name |
| Thread name. More... | |
| stkalign_t * | wbase |
| Pointer to the working area base. More... | |
| stkalign_t * | wend |
| Pointer to the working area end. More... | |
| tprio_t | prio |
| Thread priority. More... | |
| tfunc_t | funcp |
| Thread function pointer. More... | |
| void * | arg |
| Thread argument. More... | |
| os_instance_t * | instance |
OS instance affinity or NULL for current one. More... | |
Detailed Description
Type of a thread descriptor.
Definition at line 57 of file chthreads.h.
Field Documentation
◆ name
| const char* thread_descriptor_t::name |
Thread name.
Definition at line 61 of file chthreads.h.
◆ wbase
| stkalign_t* thread_descriptor_t::wbase |
Pointer to the working area base.
Definition at line 65 of file chthreads.h.
Referenced by chThdCreate(), chThdCreateI(), and chThdCreateSuspended().
◆ wend
| stkalign_t* thread_descriptor_t::wend |
Pointer to the working area end.
Definition at line 69 of file chthreads.h.
Referenced by chThdCreate(), chThdCreateI(), and chThdCreateSuspended().
◆ prio
| tprio_t thread_descriptor_t::prio |
◆ funcp
| tfunc_t thread_descriptor_t::funcp |
Thread function pointer.
Definition at line 77 of file chthreads.h.
Referenced by chSysInit(), and chThdCreateI().
◆ arg
| void* thread_descriptor_t::arg |
Thread argument.
Definition at line 81 of file chthreads.h.
◆ instance
| os_instance_t* thread_descriptor_t::instance |
OS instance affinity or NULL for current one.
Definition at line 86 of file chthreads.h.
