Collaboration diagram for Checks and Assertions:

Detailed Description

Debug APIs and services:

Runtime system state and call protocol check. The following panic messages can be generated:
- SV#1, misplaced chSysDisable().
  - Called from an ISR.
  - Called from a critical zone.
- SV#2, misplaced chSysSuspend()
  - Called from an ISR.
  - Called from a critical zone.
- SV#3, misplaced chSysEnable().
  - Called from an ISR.
  - Called from a critical zone.
- SV#4, misplaced chSysLock().
  - Called from an ISR.
  - Called from a critical zone.
- SV#5, misplaced chSysUnlock().
  - Called from an ISR.
  - Not called from a critical zone.
- SV#6, misplaced chSysLockFromISR().
  - Not called from an ISR.
  - Called from a critical zone.
- SV#7, misplaced chSysUnlockFromISR().
  - Not called from an ISR.
  - Not called from a critical zone.
- SV#8, misplaced CH_IRQ_PROLOGUE().
  - Not called at ISR begin.
  - Called from a critical zone.
- SV#9, misplaced CH_IRQ_EPILOGUE().
  - CH_IRQ_PROLOGUE() missing.
  - Not called at ISR end.
  - Called from a critical zone.
- SV#10, misplaced I-class function.
  - I-class function not called from within a critical zone.
- SV#11, misplaced S-class function.
  - S-class function not called from within a critical zone.
  - Called from an ISR.
Parameters check.
Kernel assertions.

Note: Stack checks are not implemented in this module but in the port layer in an architecture-dependent way.

Debug related settings
#define	CH_DBG_STACK_FILL_VALUE 0x55
	Fill value for thread stack area in debug mode. More...

Macro Functions
#define	chDbgCheck(c)
	Function parameters check. More...

#define	chDbgAssert(c, r)
	Condition assertion. More...

Typedefs
typedef struct ch_system_debug	system_debug_t
	System debug data structure. More...

Data Structures
struct	ch_system_debug
	System debug data structure. More...

Functions
void	__dbg_check_disable (void)
	Guard code for `chSysDisable()`. More...

void	__dbg_check_suspend (void)
	Guard code for `chSysSuspend()`. More...

void	__dbg_check_enable (void)
	Guard code for `chSysEnable()`. More...

void	__dbg_check_lock (void)
	Guard code for `chSysLock()`. More...

void	__dbg_check_unlock (void)
	Guard code for `chSysUnlock()`. More...

void	__dbg_check_lock_from_isr (void)
	Guard code for `chSysLockFromIsr()`. More...

void	__dbg_check_unlock_from_isr (void)
	Guard code for `chSysUnlockFromIsr()`. More...

void	__dbg_check_enter_isr (void)
	Guard code for `CH_IRQ_PROLOGUE()`. More...

void	__dbg_check_leave_isr (void)
	Guard code for `CH_IRQ_EPILOGUE()`. More...

void	chDbgCheckClassI (void)
	I-class functions context check. More...

void	chDbgCheckClassS (void)
	S-class functions context check. More...

static void	__dbg_object_init (system_debug_t *sdp)
	Debug support initialization. More...

Macro Definition Documentation

◆ CH_DBG_STACK_FILL_VALUE

#define CH_DBG_STACK_FILL_VALUE 0x55

Fill value for thread stack area in debug mode.

Definition at line 47 of file chdebug.h.

◆ chDbgCheck

#define chDbgCheck ( c )

Value:

  do {                                                  \
  /*lint -save -e506 -e774 [2.1, 14.3] Can be a constant by design.*/       \
  if (CH_DBG_ENABLE_CHECKS != FALSE) {                                      \
    if (unlikely(!(c))) {                                                   \
  /*lint -restore*/                                                         \
      chSysHalt(__func__);                                                  \
    }                                                                       \
  }                                                                         \
} while (false)

Function parameters check.

If the condition check fails then the kernel panics and halts.

Note: The condition is tested only if the CH_DBG_ENABLE_CHECKS switch is specified in chconf.h else the macro does nothing.

Parameters

[in] c the condition to be verified to be true

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 118 of file chdebug.h.

◆ chDbgAssert

#define chDbgAssert	(	c,
		r
	)

Value:

  do {                                              \
  /*lint -save -e506 -e774 [2.1, 14.3] Can be a constant by design.*/       \
  if (CH_DBG_ENABLE_ASSERTS != FALSE) {                                     \
    if (unlikely(!(c))) {                                                   \
  /*lint -restore*/                                                         \
      chSysHalt(__func__);                                                  \
    }                                                                       \
  }                                                                         \
} while (false)

Condition assertion.

If the condition check fails then the kernel panics with a message and halts.

Note: The condition is tested only if the CH_DBG_ENABLE_ASSERTS switch is specified in chconf.h else the macro does nothing.; The remark string is not currently used except for putting a comment in the code about the assertion.

Parameters
