Collaboration diagram for LPS25H:

Detailed Description

Macros
#define	lps25hBarometerGetAxesNumber(devp) barometerGetAxesNumber(&((devp)->baro_if))
	Return the number of axes of the BaseBarometer. More...

#define	lps25hBarometerReadRaw(devp, axes) barometerReadRaw(&((devp)->baro_if), axes)
	Retrieves raw data from the BaseBarometer. More...

#define	lps25hBarometerReadCooked(devp, axes) barometerReadCooked(&((devp)->baro_if), axes)
	Retrieves cooked data from the BaseBarometer. More...

#define	lps25hBarometerSetBias(devp, bp) barometerSetBias(&((devp)->baro_if), bp)
	Set bias values for the BaseBarometer. More...

#define	lps25hBarometerResetBias(devp) barometerResetBias(&((devp)->baro_if))
	Reset bias values for the BaseBarometer. More...

#define	lps25hBarometerSetSensitivity(devp, sp) barometerSetSensitivity(&((devp)->baro_if), sp)
	Set sensitivity values for the BaseBarometer. More...

#define	lps25hBarometerResetSensitivity(devp) barometerResetSensitivity(&((devp)->baro_if))
	Reset sensitivity values for the BaseBarometer. More...

#define	lps25hThermometerGetAxesNumber(devp) thermometerGetAxesNumber(&((devp)->thermo_if))
	Return the number of axes of the BaseThermometer. More...

#define	lps25hThermometerReadRaw(devp, axes) thermometerReadRaw(&((devp)->thermo_if), axes)
	Retrieves raw data from the BaseThermometer. More...

#define	lps25hThermometerReadCooked(devp, axes) thermometerReadCooked(&((devp)->thermo_if), axes)
	Retrieves cooked data from the BaseThermometer. More...

#define	lps25hThermometerSetBias(devp, bp) thermometerSetBias(&((devp)->thermo_if), bp)
	Set bias values for the BaseThermometer. More...

#define	lps25hThermometerResetBias(devp) thermometerResetBias(&((devp)->thermo_if))
	Reset bias values for the BaseThermometer. More...

#define	lps25hThermometerSetSensitivity(devp, sp) thermometerSetSensitivity(&((devp)->thermo_if), sp)
	Set sensitivity values for the BaseThermometer. More...

#define	lps25hThermometerResetSensitivity(devp) thermometerResetSensitivity(&((devp)->thermo_if))
	Reset sensitivity values for the BaseThermometer. More...

Version identification
#define	EX_LPS25H_VERSION "1.1.2"
	LPS25H driver version string. More...

#define	EX_LPS25H_MAJOR 1
	LPS25H driver version major number. More...

#define	EX_LPS25H_MINOR 1
	LPS25H driver version minor number. More...

#define	EX_LPS25H_PATCH 2
	LPS25H driver version patch number. More...

#define	LPS25H_BARO_NUMBER_OF_AXES 1U
	LPS25H barometer subsystem characteristics. More...

#define	LPS25H_THERMO_NUMBER_OF_AXES 1U
	LPS25H thermometer subsystem characteristics. More...

LPS25H communication interfaces related bit masks
#define	LPS25H_DI_MASK 0xFF

#define	LPS25H_DI(n) (1 << n)

#define	LPS25H_AD_MASK 0x3F

#define	LPS25H_AD(n) (1 << n)

#define	LPS25H_MS (1 << 6)

#define	LPS25H_RW (1 << 7)

#define	LPS25H_SUB_MS (1 << 7)

LPS25H register addresses
#define	LPS25H_AD_REF_P_XL 0x08

#define	LPS25H_AD_REF_P_L 0x09

#define	LPS25H_AD_REF_P_H 0x0A

#define	LPS25H_AD_WHO_AM_I 0x0F

#define	LPS25H_AD_RES_CONF 0x10

#define	LPS25H_AD_CTRL_REG1 0x20

#define	LPS25H_AD_CTRL_REG2 0x21

#define	LPS25H_AD_CTRL_REG3 0x22

#define	LPS25H_AD_CTRL_REG4 0x23

#define	LPS25H_AD_INT_CFG 0x24

#define	LPS25H_AD_INT_SRC 0x25

#define	LPS25H_AD_STATUS_REG 0x27

#define	LPS25H_AD_PRESS_OUT_XL 0x28

#define	LPS25H_AD_PRESS_OUT_L 0x29

#define	LPS25H_AD_PRESS_OUT_H 0x2A

#define	LPS25H_AD_TEMP_OUT_L 0x2B

#define	LPS25H_AD_TEMP_OUT_H 0x2C

#define	LPS25H_AD_FIFO_CTRL 0x2E

#define	LPS25H_AD_FIFO_SRC 0x2F

#define	LPS25H_AD_THS_P_L 0x30

#define	LPS25H_AD_THS_P_H 0x31

#define	LPS25H_AD_RPDS_L 0x39

#define	LPS25H_AD_RPDS_H 0x3A

LPS25H_CTRL_REG1 register bits definitions
#define	LPS25H_CTRL_REG1_MASK 0xFF

#define	LPS25H_CTRL_REG1_SIM (1 << 0)

#define	LPS25H_CTRL_REG1_RESET_AZ (1 << 1)

#define	LPS25H_CTRL_REG1_BDU (1 << 2)

#define	LPS25H_CTRL_REG1_DIFF_EN (1 << 3)

#define	LPS25H_CTRL_REG1_ODR0 (1 << 4)

#define	LPS25H_CTRL_REG1_ODR1 (1 << 5)

#define	LPS25H_CTRL_REG1_ODR2 (1 << 6)

#define	LPS25H_CTRL_REG1_PD (1 << 7)

LPS25H_CTRL_REG2 register bits definitions
#define	LPS25H_CTRL_REG2_MASK 0xF3

#define	LPS25H_CTRL_REG2_ONE_SHOT (1 << 0)

#define	LPS25H_CTRL_REG2_AUTO_ZERO (1 << 1)

#define	LPS25H_CTRL_REG2_SWRESET (1 << 2)

#define	LPS25H_CTRL_REG2_FIFO_MEAN_DEC (1 << 4)

#define	LPS25H_CTRL_REG2_WTM_EN (1 << 5)

#define	LPS25H_CTRL_REG2_FIFO_EN (1 << 6)

#define	LPS25H_CTRL_REG2_BOOT (1 << 7)

LPS25H_CTRL_REG3 register bits definitions
#define	LPS25H_CTRL_REG3_MASK 0xC3

#define	LPS25H_CTRL_REG3_INT_S1 (1 << 0)

#define	LPS25H_CTRL_REG3_INT_S2 (1 << 1)

#define	LPS25H_CTRL_REG3_PP_OD (1 << 6)

#define	LPS25H_CTRL_REG3_INT_H_L (1 << 7)

LPS25H_CTRL_REG4 register bits definitions
#define	LPS25H_CTRL_REG4_MASK 0x0F

#define	LPS25H_CTRL_REG4_P1_DRDY (1 << 0)

#define	LPS25H_CTRL_REG4_P1_OVERRUN (1 << 1)

#define	LPS25H_CTRL_REG4_P1_WTM (1 << 2)

#define	LPS25H_CTRL_REG4_P1_EMPTY (1 << 3)

LPS25H_INT1_CFG register bits definitions
#define	LPS25H_INT1_CFG_MASK 0x07

#define	LPS25H_INT1_CFG_PH_E (1 << 0)

#define	LPS25H_INT1_CFG_PL_E (1 << 1)

#define	LPS25H_INT1_CFG_LIR (1 << 2)

LPS25H_INT1_SRC register bits definitions
#define	LPS25H_INT1_SRC_MASK 0x07

#define	LPS25H_INT1_SRC_PH (1 << 0)

#define	LPS25H_INT1_SRC_PL (1 << 1)

#define	LPS25H_INT1_SRC_IA (1 << 2)

Configuration options
#define	LPS25H_USE_SPI FALSE
	LPS25H SPI interface switch. More...

#define	LPS25H_SHARED_SPI FALSE
	LPS25H shared SPI switch. More...

#define	LPS25H_USE_I2C TRUE
	LPS25H I2C interface switch. More...

#define	LPS25H_SHARED_I2C FALSE
	LPS25H shared I2C switch. More...

#define	LPS25H_USE_ADVANCED FALSE
	LPS25H advanced configurations switch. More...

LPS25H data structures and types.
enum	lps25h_sad_t { LPS25H_SAD_GND = 0x5C, LPS25H_SAD_VCC = 0x5D }
	LPS25H slave address. More...

enum	lps25h_odr_t { LPS25H_ODR_ONE_SHOT = 0x00, LPS25H_ODR_1HZ = 0x10, LPS25H_ODR_7HZ = 0x20, LPS25H_ODR_12P5HZ = 0x30, LPS25H_ODR_25HZ = 0x40 }
	LPS25H output data rate and bandwidth. More...

enum	lps25h_avgp_t { LPS25H_AVGP_8 = 0x00, LPS25H_AVGP_32 = 0x01, LPS25H_AVGP_128 = 0x02, LPS25H_AVGP_512 = 0x03 }
	LPS25H pressure resolution. More...

enum	lps25h_avgt_t { LPS25H_AVGT_8 = 0x00, LPS25H_AVGT_32 = 0x04, LPS25H_AVGT_128 = 0x08, LPS25H_AVGT_512 = 0x0C }
	LPS25H temperature resolution. More...

enum	lps25h_bdu_t { LPS25H_BDU_CONTINUOUS = 0x00, LPS25H_BDU_BLOCKED = 0x40 }
	LPS25H block data update. More...

enum	lps25h_state_t { LPS25H_UNINIT = 0, LPS25H_STOP = 1, LPS25H_READY = 2 }
	Driver state machine possible states. More...

typedef struct LPS25HDriver	LPS25HDriver
	Structure representing a LPS25H driver. More...

#define	_lps25h_methods_alone
	`LPS25H` specific methods. More...

#define	_lps25h_methods
	`LPS25H` specific methods with inherited ones. More...

#define	_lps25h_data
	`LPS25HDriver` specific data. More...

Data Structures
struct	LPS25HConfig
	LPS25H configuration structure. More...

struct	LPS25HVMT
	`LPS25H` virtual methods table. More...

struct	LPS25HDriver
	LPS25H 2-axis barometer/thermometer class. More...

Functions
static msg_t	lps25hI2CReadRegister (I2CDriver i2cp, lps25h_sad_t sad, uint8_t reg, uint8_t rxbuf, size_t n)
	Reads registers value using I2C. More...

static msg_t	lps25hI2CWriteRegister (I2CDriver i2cp, lps25h_sad_t sad, uint8_t txbuf, size_t n)
	Writes a value into a register using I2C. More...

static size_t	baro_get_axes_number (void *ip)
	Return the number of axes of the BaseBarometer. More...

static msg_t	baro_read_raw (void *ip, int32_t axes[])
	Retrieves raw data from the BaseBarometer. More...

static msg_t	baro_read_cooked (void *ip, float axes[])
	Retrieves cooked data from the BaseBarometer. More...

static msg_t	baro_set_bias (void ip, float bp)
	Set bias values for the BaseBarometer. More...

static msg_t	baro_reset_bias (void *ip)
	Reset bias values for the BaseBarometer. More...

static msg_t	baro_set_sensitivity (void ip, float sp)
	Set sensitivity values for the BaseBarometer. More...

static msg_t	baro_reset_sensitivity (void *ip)
	Reset sensitivity values for the BaseBarometer. More...

static size_t	thermo_get_axes_number (void *ip)
	Return the number of axes of the BaseThermometer. More...

static msg_t	thermo_read_raw (void *ip, int32_t axes[])
	Retrieves raw data from the BaseThermometer. More...

static msg_t	thermo_read_cooked (void ip, float axis)
	Retrieves cooked data from the BaseThermometer. More...

static msg_t	thermo_set_bias (void ip, float bp)
	Set bias values for the BaseThermometer. More...

static msg_t	thermo_reset_bias (void *ip)
	Reset bias values for the BaseThermometer. More...

static msg_t	thermo_set_sensitivity (void ip, float sp)
	Set sensitivity values for the BaseThermometer. More...

static msg_t	thermo_reset_sensitivity (void *ip)
	Reset sensitivity values for the BaseThermometer. More...

void	lps25hObjectInit (LPS25HDriver *devp)
	Initializes an instance. More...

void	lps25hStart (LPS25HDriver devp, const LPS25HConfig config)
	Configures and activates LPS25H Complex Driver peripheral. More...

void	lps25hStop (LPS25HDriver *devp)
	Deactivates the LPS25H Complex Driver peripheral. More...

Macro Definition Documentation

◆ EX_LPS25H_VERSION

#define EX_LPS25H_VERSION "1.1.2"

LPS25H driver version string.

Definition at line 46 of file lps25h.h.

◆ EX_LPS25H_MAJOR

#define EX_LPS25H_MAJOR 1

LPS25H driver version major number.

Definition at line 51 of file lps25h.h.

◆ EX_LPS25H_MINOR

#define EX_LPS25H_MINOR 1

LPS25H driver version minor number.

Definition at line 56 of file lps25h.h.

◆ EX_LPS25H_PATCH

#define EX_LPS25H_PATCH 2

LPS25H driver version patch number.

Definition at line 61 of file lps25h.h.

◆ LPS25H_BARO_NUMBER_OF_AXES

#define LPS25H_BARO_NUMBER_OF_AXES 1U

LPS25H barometer subsystem characteristics.

Note: Sensitivity is expressed as hPa/LSB whereas hPa stand for hectopascal.; Bias is expressed as hPa.

Definition at line 72 of file lps25h.h.

◆ LPS25H_THERMO_NUMBER_OF_AXES

#define LPS25H_THERMO_NUMBER_OF_AXES 1U

LPS25H thermometer subsystem characteristics.

Note: Sensitivity is expressed as �C/LSB.; Bias is expressed as �C.

Definition at line 85 of file lps25h.h.

◆ LPS25H_USE_SPI

#define LPS25H_USE_SPI FALSE

LPS25H SPI interface switch.

If set to TRUE the support for SPI is included.

Note: The default is FALSE.

Definition at line 219 of file lps25h.h.

◆ LPS25H_SHARED_SPI

#define LPS25H_SHARED_SPI FALSE

LPS25H shared SPI switch.

If set to TRUE the device acquires SPI bus ownership on each transaction.

Note: The default is FALSE. Requires SPI_USE_MUTUAL_EXCLUSION.

Definition at line 229 of file lps25h.h.

◆ LPS25H_USE_I2C

#define LPS25H_USE_I2C TRUE

LPS25H I2C interface switch.

If set to TRUE the support for I2C is included.

Note: The default is TRUE.

Definition at line 238 of file lps25h.h.

◆ LPS25H_SHARED_I2C

#define LPS25H_SHARED_I2C FALSE

LPS25H shared I2C switch.

If set to TRUE the device acquires I2C bus ownership on each transaction.

Note: The default is FALSE. Requires I2C_USE_MUTUAL_EXCLUSION.

Definition at line 248 of file lps25h.h.

◆ LPS25H_USE_ADVANCED

#define LPS25H_USE_ADVANCED FALSE

LPS25H advanced configurations switch.

If set to TRUE more configurations are available.

Note: The default is FALSE.

Definition at line 257 of file lps25h.h.

◆ _lps25h_methods_alone

#define _lps25h_methods_alone

LPS25H specific methods.

Note: No methods so far, just a common ancestor interface.

Definition at line 430 of file lps25h.h.

◆ _lps25h_methods

#define _lps25h_methods

Value:

_base_object_methods \

_lps25h_methods_alone

LPS25H specific methods with inherited ones.

Definition at line 435 of file lps25h.h.

◆ _lps25h_data

#define _lps25h_data

Value:

  /* Driver state.*/                                                        \
  lps25h_state_t            state;                                          \
  /* Current configuration data.*/                                          \
  const LPS25HConfig        *config;                                        \
  /* Barometer subsystem axes number.*/                                     \
  size_t                    baroaxes;                                       \
  /* Barometer subsystem current sensitivity.*/                             \
  float                     barosensitivity;                                \
  /* Barometer subsystem current bias .*/                                   \
  float                     barobias;                                       \
  /* Thermometer subsystem axes number.*/                                   \
  size_t                    thermoaxes;                                     \
  /* Thermometer subsystem current sensitivity.*/                           \
  float                     thermosensitivity;                              \
  /* Thermometer subsystem current bias.*/                                  \
  float                     thermobias;

LPS25HDriver specific data.

Definition at line 451 of file lps25h.h.

◆ lps25hBarometerGetAxesNumber

#define lps25hBarometerGetAxesNumber ( devp ) barometerGetAxesNumber(&((devp)->baro_if))

Return the number of axes of the BaseBarometer.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: the number of axes.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 496 of file lps25h.h.

◆ lps25hBarometerReadRaw

#define lps25hBarometerReadRaw	(	devp,
		axes
	)	barometerReadRaw(&((devp)->baro_if), axes)

Retrieves raw data from the BaseBarometer.

Note: This data is retrieved from MEMS register without any algebraical manipulation.; The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[out]	axes	a buffer which would be filled with raw data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 517 of file lps25h.h.

◆ lps25hBarometerReadCooked

#define lps25hBarometerReadCooked	(	devp,
		axes
	)	barometerReadCooked(&((devp)->baro_if), axes)

Retrieves cooked data from the BaseBarometer.

Note: This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.; Final data is expressed as hPa.; The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[out]	axes	a buffer which would be filled with cooked data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 539 of file lps25h.h.

◆ lps25hBarometerSetBias

#define lps25hBarometerSetBias	(	devp,
		bp
	)	barometerSetBias(&((devp)->baro_if), bp)

Set bias values for the BaseBarometer.

Note: Bias must be expressed as hPa.; The bias buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[in]	bp	a buffer which contains biases.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 556 of file lps25h.h.

◆ lps25hBarometerResetBias

#define lps25hBarometerResetBias ( devp ) barometerResetBias(&((devp)->baro_if))

Reset bias values for the BaseBarometer.

Note: Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 571 of file lps25h.h.

◆ lps25hBarometerSetSensitivity

#define lps25hBarometerSetSensitivity	(	devp,
		sp
	)	barometerSetSensitivity(&((devp)->baro_if), sp)

Set sensitivity values for the BaseBarometer.

Note: Sensitivity must be expressed as hPa/LSB.; The sensitivity buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[in]	sp	a buffer which contains sensitivities.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 588 of file lps25h.h.

◆ lps25hBarometerResetSensitivity

#define lps25hBarometerResetSensitivity ( devp ) barometerResetSensitivity(&((devp)->baro_if))

Reset sensitivity values for the BaseBarometer.

Note: Default sensitivities value are obtained from device datasheet.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 602 of file lps25h.h.

◆ lps25hThermometerGetAxesNumber

#define lps25hThermometerGetAxesNumber ( devp ) thermometerGetAxesNumber(&((devp)->thermo_if))

Return the number of axes of the BaseThermometer.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: the number of axes.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 614 of file lps25h.h.

◆ lps25hThermometerReadRaw

#define lps25hThermometerReadRaw	(	devp,
		axes
	)	thermometerReadRaw(&((devp)->thermo_if), axes)

Retrieves raw data from the BaseThermometer.

Note: This data is retrieved from MEMS register without any algebraical manipulation.; The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[out]	axes	a buffer which would be filled with raw data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 635 of file lps25h.h.

◆ lps25hThermometerReadCooked

#define lps25hThermometerReadCooked	(	devp,
		axes
	)	thermometerReadCooked(&((devp)->thermo_if), axes)

Retrieves cooked data from the BaseThermometer.

Note: This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.; Final data is expressed as °C.; The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[out]	axes	a buffer which would be filled with cooked data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 657 of file lps25h.h.

◆ lps25hThermometerSetBias

#define lps25hThermometerSetBias	(	devp,
		bp
	)	thermometerSetBias(&((devp)->thermo_if), bp)

Set bias values for the BaseThermometer.

Note: Bias must be expressed as °C.; The bias buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[in]	bp	a buffer which contains biases.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 674 of file lps25h.h.

◆ lps25hThermometerResetBias

#define lps25hThermometerResetBias ( devp ) thermometerResetBias(&((devp)->thermo_if))

Reset bias values for the BaseThermometer.

Note: Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 689 of file lps25h.h.

◆ lps25hThermometerSetSensitivity

#define lps25hThermometerSetSensitivity	(	devp,
		sp
	)	thermometerSetSensitivity(&((devp)->thermo_if), sp)

Set sensitivity values for the BaseThermometer.

Note: Sensitivity must be expressed as °C/LSB.; The sensitivity buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to `LPS25HDriver`.
[in]	sp	a buffer which contains sensitivities.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 706 of file lps25h.h.

◆ lps25hThermometerResetSensitivity

#define lps25hThermometerResetSensitivity ( devp ) thermometerResetSensitivity(&((devp)->thermo_if))

Reset sensitivity values for the BaseThermometer.

Note: Default sensitivities value are obtained from device datasheet.

Parameters

[in] devp pointer to LPS25HDriver.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 720 of file lps25h.h.

Typedef Documentation

◆ LPS25HDriver

typedef struct LPS25HDriver LPS25HDriver

Structure representing a LPS25H driver.

Definition at line 303 of file lps25h.h.

Enumeration Type Documentation

◆ lps25h_sad_t

enum lps25h_sad_t

LPS25H slave address.

Enumerator
LPS25H_SAD_GND	Slave Address when SA0 is to GND
LPS25H_SAD_VCC	Slave Address when SA0 is to VCC

Definition at line 308 of file lps25h.h.

◆ lps25h_odr_t

enum lps25h_odr_t

LPS25H output data rate and bandwidth.

Enumerator
LPS25H_ODR_ONE_SHOT	One shot.
LPS25H_ODR_1HZ	Output data rate 1 Hz.
LPS25H_ODR_7HZ	Output data rate 7 Hz.
LPS25H_ODR_12P5HZ	Output data rate 12.5 Hz.
LPS25H_ODR_25HZ	Output data rate 25 Hz.

Definition at line 316 of file lps25h.h.

◆ lps25h_avgp_t

enum lps25h_avgp_t

LPS25H pressure resolution.

Enumerator
LPS25H_AVGP_8	Number of internal average is 8.
LPS25H_AVGP_32	Number of internal average is 32.
LPS25H_AVGP_128	Number of internal average is 128.
LPS25H_AVGP_512	Number of internal average is 512.

Definition at line 327 of file lps25h.h.

◆ lps25h_avgt_t

enum lps25h_avgt_t

LPS25H temperature resolution.

Enumerator
LPS25H_AVGT_8	Number of internal average is 8.
LPS25H_AVGT_32	Number of internal average is 32.
LPS25H_AVGT_128	Number of internal average is 128.
LPS25H_AVGT_512	Number of internal average is 512.

Definition at line 337 of file lps25h.h.

◆ lps25h_bdu_t

enum lps25h_bdu_t

LPS25H block data update.

Enumerator
LPS25H_BDU_CONTINUOUS	Block data continuously updated.
LPS25H_BDU_BLOCKED	Block data updated after reading.

Definition at line 347 of file lps25h.h.

◆ lps25h_state_t

enum lps25h_state_t

Driver state machine possible states.

Enumerator
LPS25H_UNINIT	Not initialized.
LPS25H_STOP	Stopped.
LPS25H_READY	Ready.

Definition at line 355 of file lps25h.h.

Function Documentation

◆ lps25hI2CReadRegister()

static msg_t lps25hI2CReadRegister	(	I2CDriver *	i2cp,
		lps25h_sad_t	sad,
		uint8_t	reg,
		uint8_t *	rxbuf,
		size_t	n
	)

static

Reads registers value using I2C.

Precondition: The I2C interface must be initialized and the driver started.

Parameters

[in]	i2cp	pointer to the I2C interface
[in]	sad	slave address without R bit
[in]	reg	first sub-register address
[out]	rxbuf	pointer to an output buffer
[in]	n	number of consecutive register to read

Returns: the operation status.

Function Class:: Not an API, this function is for internal use only.

Definition at line 63 of file lps25h.c.

Referenced by baro_read_raw(), and thermo_read_raw().

◆ lps25hI2CWriteRegister()

static msg_t lps25hI2CWriteRegister	(	I2CDriver *	i2cp,
		lps25h_sad_t	sad,
		uint8_t *	txbuf,
		size_t	n
	)

static

Writes a value into a register using I2C.

Precondition: The I2C interface must be initialized and the driver started.

Parameters

[in]	i2cp	pointer to the I2C interface
[in]	sad	slave address without R bit
[in]	txbuf	buffer containing sub-address value in first position and values to write
[in]	n	size of txbuf less one (not considering the first element)

Returns: the operation status.

Function Class:: Not an API, this function is for internal use only.

Definition at line 87 of file lps25h.c.

◆ baro_get_axes_number()

static size_t baro_get_axes_number ( void * ip )

static

Return the number of axes of the BaseBarometer.

Parameters

[in] ip pointer to BaseBarometer interface.

Returns: the number of axes.

Definition at line 103 of file lps25h.c.

References LPS25H_BARO_NUMBER_OF_AXES.

◆ baro_read_raw()

static msg_t baro_read_raw	(	void *	ip,
		int32_t	axes[]
	)

static

Retrieves raw data from the BaseBarometer.

Note: This data is retrieved from MEMS register without any algebraical manipulation.; The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to `BaseBarometer` interface.
[out]	axes	a buffer which would be filled with raw data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 125 of file lps25h.c.

References I2C_READY, i2cAcquireBus(), i2cStart(), LPS25H_READY, lps25hI2CReadRegister(), objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by baro_read_cooked().

Here is the call graph for this function:

◆ baro_read_cooked()

static msg_t baro_read_cooked	(	void *	ip,
		float	axes[]
	)

static

Retrieves cooked data from the BaseBarometer.

Note: This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.; Final data is expressed as hPa.; The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to `BaseBarometer` interface.
[out]	axes	a buffer which would be filled with cooked data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 177 of file lps25h.c.

References baro_read_raw(), LPS25H_READY, objGetInstance, osalDbgAssert, and osalDbgCheck.

Here is the call graph for this function:

◆ baro_set_bias()

static msg_t baro_set_bias	(	void *	ip,
		float *	bp
	)

static

Set bias values for the BaseBarometer.

Note: Bias must be expressed as hPa.; The bias buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to `BaseBarometer` interface.
[in]	bp	a buffer which contains biases.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 212 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ baro_reset_bias()

static msg_t baro_reset_bias ( void * ip )

static

Reset bias values for the BaseBarometer.

Note: Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in] ip pointer to BaseBarometer interface.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 238 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ baro_set_sensitivity()

static msg_t baro_set_sensitivity	(	void *	ip,
		float *	sp
	)

static

Set sensitivity values for the BaseBarometer.

Note: Sensitivity must be expressed as hPa/LSB.; The sensitivity buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to `BaseBarometer` interface.
[in]	sp	a buffer which contains sensitivities.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 266 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ baro_reset_sensitivity()

static msg_t baro_reset_sensitivity ( void * ip )

static

Reset sensitivity values for the BaseBarometer.

Note: Default sensitivities value are obtained from device datasheet.

Parameters

[in] ip pointer to BaseBarometer interface.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 291 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ thermo_get_axes_number()

static size_t thermo_get_axes_number ( void * ip )

static

Return the number of axes of the BaseThermometer.

Parameters

[in] ip pointer to BaseThermometer interface.

Returns: the number of axes.

Definition at line 314 of file lps25h.c.

References LPS25H_THERMO_NUMBER_OF_AXES.

◆ thermo_read_raw()

static msg_t thermo_read_raw	(	void *	ip,
		int32_t	axes[]
	)

static

Retrieves raw data from the BaseThermometer.

Note: This data is retrieved from MEMS register without any algebraical manipulation.; The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to `BaseThermometer` interface.
[out]	axes	a buffer which would be filled with raw data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 336 of file lps25h.c.

References I2C_READY, i2cAcquireBus(), i2cStart(), LPS25H_READY, lps25hI2CReadRegister(), objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_read_cooked().

Here is the call graph for this function:

◆ thermo_read_cooked()

static msg_t thermo_read_cooked	(	void *	ip,
		float *	axis
	)

static

Retrieves cooked data from the BaseThermometer.

Note: This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.; Final data is expressed as °C.; The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to `BaseThermometer` interface.
[out]	axis	a buffer which would be filled with cooked data.

Returns: The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using `i2cGetErrors()`.
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 390 of file lps25h.c.

References LPS25H_READY, objGetInstance, osalDbgAssert, osalDbgCheck, and thermo_read_raw().

Here is the call graph for this function:

◆ thermo_set_bias()

static msg_t thermo_set_bias	(	void *	ip,
		float *	bp
	)

static

Set bias values for the BaseThermometer.

Note: Bias must be expressed as °C.; The bias buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to `BaseThermometer` interface.
[in]	bp	a buffer which contains biases.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 422 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ thermo_reset_bias()

static msg_t thermo_reset_bias ( void * ip )

static

Reset bias values for the BaseThermometer.

Note: Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in] ip pointer to BaseThermometer interface.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 449 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ thermo_set_sensitivity()

static msg_t thermo_set_sensitivity	(	void *	ip,
		float *	sp
	)

static

Set sensitivity values for the BaseThermometer.

Note: Sensitivity must be expressed as °C/LSB.; The sensitivity buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to `BaseThermometer` interface.
[in]	sp	a buffer which contains sensitivities.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 478 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ thermo_reset_sensitivity()

static msg_t thermo_reset_sensitivity ( void * ip )

static

Reset sensitivity values for the BaseThermometer.

Note: Default sensitivities value are obtained from device datasheet.

Parameters

[in] ip pointer to BaseThermometer interface.

Returns: The operation status.

Return values

MSG_OK if the function succeeded.

Definition at line 504 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

◆ lps25hObjectInit()

void lps25hObjectInit ( LPS25HDriver * devp )

Initializes an instance.

Parameters

[out] devp pointer to the LPS25HDriver object

Function Class:: Initializer, this function just initializes an object and can be invoked before the kernel is initialized.

Definition at line 550 of file lps25h.c.

References LPS25HDriver::vmt.

◆ lps25hStart()

void lps25hStart	(	LPS25HDriver *	devp,
		const LPS25HConfig *	config
	)

Configures and activates LPS25H Complex Driver peripheral.

Parameters

[in]	devp	pointer to the `LPS25HDriver` object
[in]	config	pointer to the `LPS25HConfig` object

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 572 of file lps25h.c.

References LPS25H_READY, LPS25H_STOP, osalDbgAssert, and osalDbgCheck.

◆ lps25hStop()

void lps25hStop ( LPS25HDriver * devp )

Deactivates the LPS25H Complex Driver peripheral.

Parameters

[in] devp pointer to the LPS25HDriver object

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 669 of file lps25h.c.

References i2cAcquireBus(), i2cStart(), LPS25H_READY, LPS25H_STOP, osalDbgAssert, and osalDbgCheck.

Here is the call graph for this function:

Detailed Description

Macros

Version identification

LPS25H communication interfaces related bit masks

LPS25H register addresses

LPS25H_CTRL_REG1 register bits definitions

LPS25H_CTRL_REG2 register bits definitions

LPS25H_CTRL_REG3 register bits definitions

LPS25H_CTRL_REG4 register bits definitions

LPS25H_INT1_CFG register bits definitions

LPS25H_INT1_SRC register bits definitions

Configuration options

LPS25H data structures and types.

Data Structures

Functions

Macro Definition Documentation

◆ EX_LPS25H_VERSION

◆ EX_LPS25H_MAJOR

◆ EX_LPS25H_MINOR

◆ EX_LPS25H_PATCH

◆ LPS25H_BARO_NUMBER_OF_AXES

◆ LPS25H_THERMO_NUMBER_OF_AXES

◆ LPS25H_USE_SPI

◆ LPS25H_SHARED_SPI

◆ LPS25H_USE_I2C

◆ LPS25H_SHARED_I2C

◆ LPS25H_USE_ADVANCED

◆ _lps25h_methods_alone

◆ _lps25h_methods

◆ _lps25h_data

◆ lps25hBarometerGetAxesNumber

◆ lps25hBarometerReadRaw

◆ lps25hBarometerReadCooked

◆ lps25hBarometerSetBias

◆ lps25hBarometerResetBias

◆ lps25hBarometerSetSensitivity

◆ lps25hBarometerResetSensitivity

◆ lps25hThermometerGetAxesNumber

◆ lps25hThermometerReadRaw

◆ lps25hThermometerReadCooked

◆ lps25hThermometerSetBias

◆ lps25hThermometerResetBias

◆ lps25hThermometerSetSensitivity

◆ lps25hThermometerResetSensitivity

Typedef Documentation

◆ LPS25HDriver

Enumeration Type Documentation

◆ lps25h_sad_t

◆ lps25h_odr_t

◆ lps25h_avgp_t

◆ lps25h_avgt_t

◆ lps25h_bdu_t

◆ lps25h_state_t

Function Documentation

◆ lps25hI2CReadRegister()

◆ lps25hI2CWriteRegister()

◆ baro_get_axes_number()

◆ baro_read_raw()

◆ baro_read_cooked()

◆ baro_set_bias()

◆ baro_reset_bias()

◆ baro_set_sensitivity()

◆ baro_reset_sensitivity()

◆ thermo_get_axes_number()

◆ thermo_read_raw()

◆ thermo_read_cooked()

◆ thermo_set_bias()

◆ thermo_reset_bias()

◆ thermo_set_sensitivity()

◆ thermo_reset_sensitivity()

◆ lps25hObjectInit()

◆ lps25hStart()

◆ lps25hStop()
