Type of a MFS configuration structure. More...
#include <mfs.h>
Data Fields | |
| BaseFlash * | flashp |
| Flash driver associated to this MFS instance. More... | |
| uint32_t | erased |
| Erased value. More... | |
| flash_offset_t | bank_size |
| Banks size. More... | |
| flash_sector_t | bank0_start |
| Base sector index for bank 0. More... | |
| flash_sector_t | bank0_sectors |
| Number of sectors for bank 0. More... | |
| flash_sector_t | bank1_start |
| Base sector index for bank 1. More... | |
| flash_sector_t | bank1_sectors |
| Number of sectors for bank 1. More... | |
Detailed Description
Field Documentation
| BaseFlash* MFSConfig::flashp |
Flash driver associated to this MFS instance.
Definition at line 256 of file mfs.h.
Referenced by mfs_bank_erase(), mfs_bank_verify_erase(), mfs_bank_write_header(), mfs_flash_read(), and mfs_flash_write().
| uint32_t MFSConfig::erased |
Erased value.
Definition at line 260 of file mfs.h.
Referenced by mfs_bank_get_state(), mfs_bank_write_header(), mfs_record_check(), and mfsWriteRecord().
| flash_offset_t MFSConfig::bank_size |
Banks size.
Definition at line 264 of file mfs.h.
Referenced by mfs_bank_scan_records(), mfsEraseRecord(), and mfsWriteRecord().
| flash_sector_t MFSConfig::bank0_start |
Base sector index for bank 0.
Definition at line 268 of file mfs.h.
Referenced by mfs_bank_erase(), mfs_bank_verify_erase(), and mfs_bank_write_header().
| flash_sector_t MFSConfig::bank0_sectors |
Number of sectors for bank 0.
- Note
- The total size of bank0 sectors must be greater or equal to
bank_size.
Definition at line 274 of file mfs.h.
Referenced by mfs_bank_erase(), and mfs_bank_verify_erase().
| flash_sector_t MFSConfig::bank1_start |
Base sector index for bank 1.
Definition at line 278 of file mfs.h.
Referenced by mfs_bank_erase(), mfs_bank_verify_erase(), and mfs_bank_write_header().
| flash_sector_t MFSConfig::bank1_sectors |
Number of sectors for bank 1.
- Note
- The total size of bank1 sectors must be greater or equal to
bank_size.
Definition at line 284 of file mfs.h.
Referenced by mfs_bank_erase(), and mfs_bank_verify_erase().
