Dynamic Threads

Collaboration diagram for Dynamic Threads:

Detailed Description

Dynamic threads related APIs and services.

Functions
thread_t *	chThdCreateFromHeap (memory_heap_t *heapp, size_t size, const char *name, tprio_t prio, tfunc_t pf, void *arg)
	Creates a new thread allocating the memory from the heap. More...
thread_t *	chThdCreateFromMemoryPool (memory_pool_t *mp, const char *name, tprio_t prio, tfunc_t pf, void *arg)
	Creates a new thread allocating the memory from the specified memory pool. More...

Function Documentation

thread_t * chThdCreateFromHeap	(	memory_heap_t *	heapp,
		size_t	size,
		const char *	name,
		tprio_t	prio,
		tfunc_t	pf,
		void *	arg
	)

Creates a new thread allocating the memory from the heap.

Precondition

The configuration options CH_CFG_USE_DYNAMIC and CH_CFG_USE_HEAP must be enabled in order to use this function.

Note

A thread can terminate by calling chThdExit() or by simply returning from its main function.

The memory allocated for the thread is not released automatically, it is responsibility of the creator thread to call chThdWait() and then release the allocated memory.

Parameters

[in]	heapp	heap from which allocate the memory or NULL for the default heap
[in]	size	size of the working area to be allocated
[in]	name	thread name
[in]	prio	the priority level for the new thread
[in]	pf	the thread function
[in]	arg	an argument passed to the thread function. It can be NULL.

Returns

The pointer to the thread_t structure allocated for the thread into the working space area.

Return values

NULL	if the memory cannot be allocated.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 82 of file chdynamic.c.

References _thread_memfill(), CH_DBG_STACK_FILL_VALUE, CH_FLAG_MODE_HEAP, chHeapAllocAligned(), chSchWakeupS(), chSysLock, chSysUnlock, chThdCreateSuspendedI(), ch_thread::flags, MSG_OK, and PORT_WORKING_AREA_ALIGN.

Here is the call graph for this function:

thread_t * chThdCreateFromMemoryPool	(	memory_pool_t *	mp,
		const char *	name,
		tprio_t	prio,
		tfunc_t	pf,
		void *	arg
	)

Creates a new thread allocating the memory from the specified memory pool.

Precondition

The configuration options CH_CFG_USE_DYNAMIC and CH_CFG_USE_MEMPOOLS must be enabled in order to use this function.

The pool must be initialized to contain only objects with alignment PORT_WORKING_AREA_ALIGN.

Note

A thread can terminate by calling chThdExit() or by simply returning from its main function.

The memory allocated for the thread is not released automatically, it is responsibility of the creator thread to call chThdWait() and then release the allocated memory.

Parameters

[in]	mp	pointer to the memory pool object
[in]	name	thread name
[in]	prio	the priority level for the new thread
[in]	pf	the thread function
[in]	arg	an argument passed to the thread function. It can be NULL.

Returns

The pointer to the thread_t structure allocated for the thread into the working space area.

Return values

NULL	if the memory pool is empty.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 145 of file chdynamic.c.

References _thread_memfill(), CH_DBG_STACK_FILL_VALUE, CH_FLAG_MODE_MPOOL, chDbgCheck, chPoolAlloc(), chSchWakeupS(), chSysLock, chSysUnlock, chThdCreateSuspendedI(), ch_thread::flags, ch_thread::mpool, MSG_OK, and memory_pool_t::object_size.

Here is the call graph for this function:
