Detailed Description

System events tracing service.

Trace record types
#define	CH_TRACE_TYPE_UNUSED 0U

#define	CH_TRACE_TYPE_READY 1U

#define	CH_TRACE_TYPE_SWITCH 2U

#define	CH_TRACE_TYPE_ISR_ENTER 3U

#define	CH_TRACE_TYPE_ISR_LEAVE 4U

#define	CH_TRACE_TYPE_HALT 5U

#define	CH_TRACE_TYPE_USER 6U

Events to trace
#define	CH_DBG_TRACE_MASK_DISABLED 255U

#define	CH_DBG_TRACE_MASK_NONE 0U

#define	CH_DBG_TRACE_MASK_READY 1U

#define	CH_DBG_TRACE_MASK_SWITCH 2U

#define	CH_DBG_TRACE_MASK_ISR 4U

#define	CH_DBG_TRACE_MASK_HALT 8U

#define	CH_DBG_TRACE_MASK_USER 16U

#define	CH_DBG_TRACE_MASK_SLOW

#define	CH_DBG_TRACE_MASK_ALL

Debug related settings
#define	CH_DBG_TRACE_MASK CH_DBG_TRACE_MASK_DISABLED
	Trace buffer entries. More...

#define	CH_DBG_TRACE_BUFFER_SIZE 128
	Trace buffer entries. More...

Data Structures
struct	trace_event_t
	Trace buffer record. More...

struct	trace_buffer_t
	Trace buffer header. More...

Functions
static NOINLINE void	trace_next (os_instance_t *oip)
	Writes a time stamp and increases the trace buffer pointer. More...

void	__trace_object_init (trace_buffer_t *tbp)
	Circular trace buffer initialization. More...

void	__trace_ready (thread_t *tp, msg_t msg)
	Inserts in the circular debug trace buffer a ready record. More...

void	__trace_switch (thread_t ntp, thread_t otp)
	Inserts in the circular debug trace buffer a context switch record. More...

void	__trace_isr_enter (const char *isr)
	Inserts in the circular debug trace buffer an ISR-enter record. More...

void	__trace_isr_leave (const char *isr)
	Inserts in the circular debug trace buffer an ISR-leave record. More...

void	__trace_halt (const char *reason)
	Inserts in the circular debug trace buffer an halt record. More...

void	chTraceWriteI (void up1, void up2)
	Adds an user trace record to the trace buffer. More...

void	chTraceWrite (void up1, void up2)
	Adds an user trace record to the trace buffer. More...

void	chTraceSuspendI (uint16_t mask)
	Suspends one or more trace events. More...

void	chTraceSuspend (uint16_t mask)
	Suspends one or more trace events. More...

void	chTraceResumeI (uint16_t mask)
	Resumes one or more trace events. More...

void	chTraceResume (uint16_t mask)
	Resumes one or more trace events. More...

Macro Definition Documentation

◆ CH_DBG_TRACE_MASK

#define CH_DBG_TRACE_MASK CH_DBG_TRACE_MASK_DISABLED

Trace buffer entries.

Definition at line 82 of file chtrace.h.

◆ CH_DBG_TRACE_BUFFER_SIZE

#define CH_DBG_TRACE_BUFFER_SIZE 128

Trace buffer entries.

Note: The trace buffer is only allocated if CH_DBG_TRACE_MASK is different from CH_DBG_TRACE_MASK_DISABLED.

Definition at line 91 of file chtrace.h.

Function Documentation

◆ trace_next()

static NOINLINE void trace_next ( os_instance_t * oip )

static

Writes a time stamp and increases the trace buffer pointer.

Function Class:: Not an API, this function is for internal use only.

Definition at line 57 of file chtrace.c.

References trace_buffer_t::buffer, CH_CFG_TRACE_HOOK, CH_DBG_TRACE_BUFFER_SIZE, chSysGetRealtimeCounterX, chVTGetSystemTimeX(), trace_buffer_t::ptr, trace_event_t::rtstamp, trace_event_t::time, and ch_os_instance::trace_buffer.

Here is the call graph for this function:

◆ __trace_object_init()

void __trace_object_init ( trace_buffer_t * tbp )

Circular trace buffer initialization.

Note: Internal use only.

Parameters

[out] tbp pointer to the trace_buffer_t structure

Function Class:: Not an API, this function is for internal use only.

Definition at line 88 of file chtrace.c.

References trace_buffer_t::suspended.

Referenced by chInstanceObjectInit().

◆ __trace_ready()

void __trace_ready	(	thread_t *	tp,
		msg_t	msg
	)

Inserts in the circular debug trace buffer a ready record.

Parameters

[in]	tp	the thread that just become ready
[in]	msg	the thread ready message

Function Class:: Not an API, this function is for internal use only.

Definition at line 107 of file chtrace.c.

References currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

Referenced by __sch_ready_ahead(), and __sch_ready_behind().

◆ __trace_switch()

void __trace_switch	(	thread_t *	ntp,
		thread_t *	otp
	)

Inserts in the circular debug trace buffer a context switch record.

Parameters

[in]	ntp	the thread being switched in
[in]	otp	the thread being switched out

Function Class:: Not an API, this function is for internal use only.

Definition at line 127 of file chtrace.c.

References currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

◆ __trace_isr_enter()

void __trace_isr_enter ( const char * isr )

Inserts in the circular debug trace buffer an ISR-enter record.

Parameters

[in] isr name of the isr

Function Class:: Not an API, this function is for internal use only.

Definition at line 146 of file chtrace.c.

References currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

◆ __trace_isr_leave()

void __trace_isr_leave ( const char * isr )

Inserts in the circular debug trace buffer an ISR-leave record.

Parameters

[in] isr name of the isr

Function Class:: Not an API, this function is for internal use only.

Definition at line 166 of file chtrace.c.

References currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

◆ __trace_halt()

void __trace_halt ( const char * reason )

Inserts in the circular debug trace buffer an halt record.

Parameters

[in] reason the halt error string

Function Class:: Not an API, this function is for internal use only.

Definition at line 186 of file chtrace.c.

References currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

Referenced by chSysHalt().

◆ chTraceWriteI()

void chTraceWriteI	(	void *	up1,
		void *	up2
	)

Adds an user trace record to the trace buffer.

Parameters

[in]	up1	user parameter 1
[in]	up2	user parameter 2

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 205 of file chtrace.c.

References chDbgCheckClassI(), currcore, trace_buffer_t::suspended, and ch_os_instance::trace_buffer.

Referenced by chTraceWrite().

Here is the call graph for this function:

◆ chTraceWrite()

void chTraceWrite	(	void *	up1,
		void *	up2
	)

Adds an user trace record to the trace buffer.

Parameters

[in]	up1	user parameter 1
[in]	up2	user parameter 2

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 227 of file chtrace.c.

References chSysLock(), chSysUnlock(), and chTraceWriteI().

Here is the call graph for this function:

◆ chTraceSuspendI()

void chTraceSuspendI ( uint16_t mask )

Suspends one or more trace events.

Parameters

[in] mask mask of the trace events to be suspended

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 241 of file chtrace.c.

References chDbgCheckClassI(), and currcore.

Referenced by chTraceSuspend().

Here is the call graph for this function:

◆ chTraceSuspend()

void chTraceSuspend ( uint16_t mask )

Suspends one or more trace events.

Parameters

[in] mask mask of the trace events to be suspended

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 255 of file chtrace.c.

References chSysLock(), chSysUnlock(), and chTraceSuspendI().

Here is the call graph for this function:

◆ chTraceResumeI()

void chTraceResumeI ( uint16_t mask )

Resumes one or more trace events.

Parameters

[in] mask mask of the trace events to be resumed

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 269 of file chtrace.c.

References chDbgCheckClassI(), and currcore.

Referenced by chTraceResume().

Here is the call graph for this function:

◆ chTraceResume()

void chTraceResume ( uint16_t mask )

Resumes one or more trace events.

Parameters

[in] mask mask of the trace events to be resumed

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 283 of file chtrace.c.

References chSysLock(), chSysUnlock(), and chTraceResumeI().

Here is the call graph for this function:
