Time Measurement

Collaboration diagram for Time Measurement:

Detailed Description

Time Measurement APIs and services.

Macros
#define	TM_CALIBRATION_LOOP   4U
	Number of iterations in the calibration loop. More...

Data Structures
struct	tm_calibration_t
	Type of a time measurement calibration data. More...
struct	time_measurement_t
	Type of a Time Measurement object. More...

Functions
void	chTMObjectInit (time_measurement_t *tmp)
	Initializes a TimeMeasurement object. More...
NOINLINE void	chTMStartMeasurementX (time_measurement_t *tmp)
	Starts a measurement. More...
NOINLINE void	chTMStopMeasurementX (time_measurement_t *tmp)
	Stops a measurement. More...
NOINLINE void	chTMChainMeasurementToX (time_measurement_t *tmp1, time_measurement_t *tmp2)
	Stops a measurement and chains to the next one using the same time stamp. More...
static void	__tm_calibration_object_init (tm_calibration_t *tcp)
	Time measurement initialization. More...

Macro Definition Documentation

TM_CALIBRATION_LOOP

#define TM_CALIBRATION_LOOP   4U

Number of iterations in the calibration loop.

Note

This is required in order to assess the best result in architectures with instruction cache.

Definition at line 42 of file chtm.h.

Function Documentation

chTMObjectInit()

void chTMObjectInit

(

time_measurement_t *

tmp

)

Initializes a TimeMeasurement object.

Parameters

[out]

tmp

pointer to a TimeMeasurement structure

Function Class:

Initializer, this function just initializes an object and can be invoked before the kernel is initialized.

Definition at line 79 of file chtm.c.

References time_measurement_t::best, time_measurement_t::cumulative, time_measurement_t::last, time_measurement_t::n, and time_measurement_t::worst.

Referenced by __stats_object_init(), __thd_object_init(), and __tm_calibration_object_init().

chTMStartMeasurementX()

NOINLINE void chTMStartMeasurementX

(

time_measurement_t *

tmp

)

Starts a measurement.

Precondition

The time_measurement_t structure must be initialized.

Parameters

[in,out]

tmp

pointer to a TimeMeasurement structure

Function Class:

This is an X-Class API, this function can be invoked from any context.

Definition at line 96 of file chtm.c.

References chSysGetRealtimeCounterX, and time_measurement_t::last.

Referenced by __stats_start_measure_crit_isr(), __stats_start_measure_crit_thd(), and __tm_calibration_object_init().

chTMStopMeasurementX()

NOINLINE void chTMStopMeasurementX

(

time_measurement_t *

tmp

)

Stops a measurement.

Precondition

The time_measurement_t structure must be initialized.

Parameters

[in,out]

tmp

pointer to a time_measurement_t structure

Function Class:

This is an X-Class API, this function can be invoked from any context.

Definition at line 109 of file chtm.c.

Referenced by __stats_stop_measure_crit_isr(), __stats_stop_measure_crit_thd(), and __tm_calibration_object_init().

chTMChainMeasurementToX()

NOINLINE void chTMChainMeasurementToX	(	time_measurement_t *	tmp1,
		time_measurement_t *	tmp2
	)

Stops a measurement and chains to the next one using the same time stamp.

Parameters

[in,out]	tmp1	pointer to the time_measurement_t structure to be stopped
[in,out]	tmp2	pointer to the time_measurement_t structure to be started

Function Class:

This is an X-Class API, this function can be invoked from any context.

Definition at line 126 of file chtm.c.

References chSysGetRealtimeCounterX, and time_measurement_t::last.

Referenced by __stats_ctxswc().

__tm_calibration_object_init()

static void __tm_calibration_object_init ( tm_calibration_t *  tcp )

inlinestatic

Time measurement initialization.

Note

Internal use only.

Parameters

[out]

tcp

pointer to the tm_calibration_t structure

Function Class:

Not an API, this function is for internal use only.

Definition at line 119 of file chtm.h.

References time_measurement_t::best, chTMObjectInit(), chTMStartMeasurementX(), chTMStopMeasurementX(), tm_calibration_t::offset, and TM_CALIBRATION_LOOP.

Here is the call graph for this function:
