Structure representing a thread. More...
#include <ch.h>
Data Fields | |
| struct port_context | ctx |
| Processor context. | |
| tstate_t | state |
| Thread state. | |
| union { | |
| msg_t msg | |
| Wake-up/exit message. More... | |
| void * p | |
| Generic pointer. More... | |
| os_instance_t * nsp | |
| Pointer to nil base struct. More... | |
| thread_reference_t * trp | |
| Pointer to thread reference. More... | |
| threads_queue_t * tqp | |
| Pointer to thread queue. More... | |
| thread_t * tp | |
| Pointer to thread. More... | |
| semaphore_t * semp | |
| Pointer to semaphore. More... | |
| eventmask_t ewmask | |
| Enabled events mask. More... | |
| } | u1 |
| volatile sysinterval_t | timeout |
| Timeout counter, zero if disabled. | |
| eventmask_t | epmask |
| Pending events mask. | |
| msg_t | sntmsg |
| Sent message. | |
| stkalign_t * | wabase |
| Thread stack boundary. | |
Detailed Description
Structure representing a thread.
Definition at line 521 of file nil/include/ch.h.
Field Documentation
◆ ctx
| struct port_context nil_thread::ctx |
Processor context.
Definition at line 522 of file nil/include/ch.h.
◆ state
| tstate_t nil_thread::state |
Thread state.
Definition at line 523 of file nil/include/ch.h.
◆ msg
| msg_t nil_thread::msg |
Wake-up/exit message.
Definition at line 527 of file nil/include/ch.h.
◆ p
| void* nil_thread::p |
Generic pointer.
Definition at line 528 of file nil/include/ch.h.
◆ nsp
| os_instance_t* nil_thread::nsp |
Pointer to nil base struct.
Definition at line 529 of file nil/include/ch.h.
◆ trp
| thread_reference_t* nil_thread::trp |
Pointer to thread reference.
Definition at line 530 of file nil/include/ch.h.
◆ tqp
| threads_queue_t* nil_thread::tqp |
Pointer to thread queue.
Definition at line 531 of file nil/include/ch.h.
◆ tp
| thread_t* nil_thread::tp |
Pointer to thread.
Definition at line 532 of file nil/include/ch.h.
◆ semp
| semaphore_t* nil_thread::semp |
Pointer to semaphore.
Definition at line 534 of file nil/include/ch.h.
◆ ewmask
| eventmask_t nil_thread::ewmask |
Enabled events mask.
Definition at line 537 of file nil/include/ch.h.
◆ [union]
| union { ... } nil_thread::u1 |
◆ timeout
| volatile sysinterval_t nil_thread::timeout |
Timeout counter, zero if disabled.
Definition at line 540 of file nil/include/ch.h.
◆ epmask
| eventmask_t nil_thread::epmask |
Pending events mask.
Definition at line 543 of file nil/include/ch.h.
◆ sntmsg
| msg_t nil_thread::sntmsg |
Sent message.
Definition at line 546 of file nil/include/ch.h.
◆ wabase
| stkalign_t* nil_thread::wabase |
Thread stack boundary.
Definition at line 549 of file nil/include/ch.h.
