LIS3DSH configuration structure. More...

#include <lis3dsh.h>

Collaboration diagram for LIS3DSHConfig:

Data Fields
SPIDriver *	spip
	SPI driver associated to this LIS3DSH. More...

const SPIConfig *	spicfg
	SPI configuration associated to this LIS3DSH. More...

I2CDriver *	i2cp
	I2C driver associated to this LIS3DSH. More...

const I2CConfig *	i2ccfg
	I2C configuration associated to this LIS3DSH. More...

float *	accsensitivity
	LIS3DSH accelerometer subsystem initial sensitivity. More...

float *	accbias
	LIS3DSH accelerometer subsystem initial bias. More...

lis3dsh_acc_fs_t	accfullscale
	LIS3DSH accelerometer subsystem initial full scale. More...

lis3dsh_acc_odr_t	accoutputdatarate
	LIS3DSH output data rate selection. More...

lis3dsh_acc_bw_t	accantialiasing
	LIS3DSH anti-aliasing bandwidth. More...

lis3dsh_acc_bdu_t	accblockdataupdate
	LIS3DSH block data update. More...

Detailed Description

LIS3DSH configuration structure.

Definition at line 446 of file lis3dsh.h.

Field Documentation

SPIDriver* LIS3DSHConfig::spip

SPI driver associated to this LIS3DSH.

Definition at line 452 of file lis3dsh.h.

const SPIConfig* LIS3DSHConfig::spicfg

SPI configuration associated to this LIS3DSH.

Definition at line 456 of file lis3dsh.h.

I2CDriver* LIS3DSHConfig::i2cp

I2C driver associated to this LIS3DSH.

Definition at line 462 of file lis3dsh.h.

const I2CConfig* LIS3DSHConfig::i2ccfg

I2C configuration associated to this LIS3DSH.

Definition at line 466 of file lis3dsh.h.

float* LIS3DSHConfig::accsensitivity

LIS3DSH accelerometer subsystem initial sensitivity.

Definition at line 471 of file lis3dsh.h.

float* LIS3DSHConfig::accbias

LIS3DSH accelerometer subsystem initial bias.

Definition at line 475 of file lis3dsh.h.

lis3dsh_acc_fs_t LIS3DSHConfig::accfullscale

LIS3DSH accelerometer subsystem initial full scale.

Definition at line 479 of file lis3dsh.h.

lis3dsh_acc_odr_t LIS3DSHConfig::accoutputdatarate

LIS3DSH output data rate selection.

Definition at line 483 of file lis3dsh.h.

lis3dsh_acc_bw_t LIS3DSHConfig::accantialiasing

LIS3DSH anti-aliasing bandwidth.

Definition at line 488 of file lis3dsh.h.

lis3dsh_acc_bdu_t LIS3DSHConfig::accblockdataupdate

LIS3DSH block data update.

Definition at line 492 of file lis3dsh.h.
