LPS25H

Collaboration diagram for LPS25H:

Detailed Description

Macros
#define	lps25hBarometerGetAxesNumber(devp)   barometerGetAxesNumber(&((devp)->baro_if))
	Return the number of axes of the BaseBarometer. More...
#define	lps25hBarometerReadRaw(devp, axes)   barometerReadRaw(&((devp)->baro_if), axes)
	Retrieves raw data from the BaseBarometer. More...
#define	lps25hBarometerReadCooked(devp, axes)   barometerReadCooked(&((devp)->baro_if), axes)
	Retrieves cooked data from the BaseBarometer. More...
#define	lps25hBarometerSetBias(devp, bp)   barometerSetBias(&((devp)->baro_if), bp)
	Set bias values for the BaseBarometer. More...
#define	lps25hBarometerResetBias(devp)   barometerResetBias(&((devp)->baro_if))
	Reset bias values for the BaseBarometer. More...
#define	lps25hBarometerSetSensitivity(devp, sp)   barometerSetSensitivity(&((devp)->baro_if), sp)
	Set sensitivity values for the BaseBarometer. More...
#define	lps25hBarometerResetSensitivity(devp)   barometerResetSensitivity(&((devp)->baro_if))
	Reset sensitivity values for the BaseBarometer. More...
#define	lps25hThermometerGetAxesNumber(devp)   thermometerGetAxesNumber(&((devp)->thermo_if))
	Return the number of axes of the BaseThermometer. More...
#define	lps25hThermometerReadRaw(devp, axes)   thermometerReadRaw(&((devp)->thermo_if), axes)
	Retrieves raw data from the BaseThermometer. More...
#define	lps25hThermometerReadCooked(devp, axes)   thermometerReadCooked(&((devp)->thermo_if), axes)
	Retrieves cooked data from the BaseThermometer. More...
#define	lps25hThermometerSetBias(devp, bp)   thermometerSetBias(&((devp)->thermo_if), bp)
	Set bias values for the BaseThermometer. More...
#define	lps25hThermometerResetBias(devp)   thermometerResetBias(&((devp)->thermo_if))
	Reset bias values for the BaseThermometer. More...
#define	lps25hThermometerSetSensitivity(devp, sp)   thermometerSetSensitivity(&((devp)->thermo_if), sp)
	Set sensitivity values for the BaseThermometer. More...
#define	lps25hThermometerResetSensitivity(devp)   thermometerResetSensitivity(&((devp)->thermo_if))
	Reset sensitivity values for the BaseThermometer. More...

Version identification
#define	EX_LPS25H_VERSION   "1.1.2"
	LPS25H driver version string. More...
#define	EX_LPS25H_MAJOR   1
	LPS25H driver version major number. More...
#define	EX_LPS25H_MINOR   1
	LPS25H driver version minor number. More...
#define	EX_LPS25H_PATCH   2
	LPS25H driver version patch number. More...
#define	LPS25H_BARO_NUMBER_OF_AXES   1U
	LPS25H barometer subsystem characteristics. More...
#define	LPS25H_THERMO_NUMBER_OF_AXES   1U
	LPS25H thermometer subsystem characteristics. More...

LPS25H communication interfaces related bit masks
#define	LPS25H_DI_MASK   0xFF
#define	LPS25H_DI(n)   (1 << n)
#define	LPS25H_AD_MASK   0x3F
#define	LPS25H_AD(n)   (1 << n)
#define	LPS25H_MS   (1 << 6)
#define	LPS25H_RW   (1 << 7)
#define	LPS25H_SUB_MS   (1 << 7)

LPS25H register addresses
#define	LPS25H_AD_REF_P_XL   0x08
#define	LPS25H_AD_REF_P_L   0x09
#define	LPS25H_AD_REF_P_H   0x0A
#define	LPS25H_AD_WHO_AM_I   0x0F
#define	LPS25H_AD_RES_CONF   0x10
#define	LPS25H_AD_CTRL_REG1   0x20
#define	LPS25H_AD_CTRL_REG2   0x21
#define	LPS25H_AD_CTRL_REG3   0x22
#define	LPS25H_AD_CTRL_REG4   0x23
#define	LPS25H_AD_INT_CFG   0x24
#define	LPS25H_AD_INT_SRC   0x25
#define	LPS25H_AD_STATUS_REG   0x27
#define	LPS25H_AD_PRESS_OUT_XL   0x28
#define	LPS25H_AD_PRESS_OUT_L   0x29
#define	LPS25H_AD_PRESS_OUT_H   0x2A
#define	LPS25H_AD_TEMP_OUT_L   0x2B
#define	LPS25H_AD_TEMP_OUT_H   0x2C
#define	LPS25H_AD_FIFO_CTRL   0x2E
#define	LPS25H_AD_FIFO_SRC   0x2F
#define	LPS25H_AD_THS_P_L   0x30
#define	LPS25H_AD_THS_P_H   0x31
#define	LPS25H_AD_RPDS_L   0x39
#define	LPS25H_AD_RPDS_H   0x3A

LPS25H_CTRL_REG1 register bits definitions
#define	LPS25H_CTRL_REG1_MASK   0xFF
#define	LPS25H_CTRL_REG1_SIM   (1 << 0)
#define	LPS25H_CTRL_REG1_RESET_AZ   (1 << 1)
#define	LPS25H_CTRL_REG1_BDU   (1 << 2)
#define	LPS25H_CTRL_REG1_DIFF_EN   (1 << 3)
#define	LPS25H_CTRL_REG1_ODR0   (1 << 4)
#define	LPS25H_CTRL_REG1_ODR1   (1 << 5)
#define	LPS25H_CTRL_REG1_ODR2   (1 << 6)
#define	LPS25H_CTRL_REG1_PD   (1 << 7)

LPS25H_CTRL_REG2 register bits definitions
#define	LPS25H_CTRL_REG2_MASK   0xF3
#define	LPS25H_CTRL_REG2_ONE_SHOT   (1 << 0)
#define	LPS25H_CTRL_REG2_AUTO_ZERO   (1 << 1)
#define	LPS25H_CTRL_REG2_SWRESET   (1 << 2)
#define	LPS25H_CTRL_REG2_FIFO_MEAN_DEC   (1 << 4)
#define	LPS25H_CTRL_REG2_WTM_EN   (1 << 5)
#define	LPS25H_CTRL_REG2_FIFO_EN   (1 << 6)
#define	LPS25H_CTRL_REG2_BOOT   (1 << 7)

LPS25H_CTRL_REG3 register bits definitions
#define	LPS25H_CTRL_REG3_MASK   0xC3
#define	LPS25H_CTRL_REG3_INT_S1   (1 << 0)
#define	LPS25H_CTRL_REG3_INT_S2   (1 << 1)
#define	LPS25H_CTRL_REG3_PP_OD   (1 << 6)
#define	LPS25H_CTRL_REG3_INT_H_L   (1 << 7)

LPS25H_CTRL_REG4 register bits definitions
#define	LPS25H_CTRL_REG4_MASK   0x0F
#define	LPS25H_CTRL_REG4_P1_DRDY   (1 << 0)
#define	LPS25H_CTRL_REG4_P1_OVERRUN   (1 << 1)
#define	LPS25H_CTRL_REG4_P1_WTM   (1 << 2)
#define	LPS25H_CTRL_REG4_P1_EMPTY   (1 << 3)

LPS25H_INT1_CFG register bits definitions
#define	LPS25H_INT1_CFG_MASK   0x07
#define	LPS25H_INT1_CFG_PH_E   (1 << 0)
#define	LPS25H_INT1_CFG_PL_E   (1 << 1)
#define	LPS25H_INT1_CFG_LIR   (1 << 2)

LPS25H_INT1_SRC register bits definitions
#define	LPS25H_INT1_SRC_MASK   0x07
#define	LPS25H_INT1_SRC_PH   (1 << 0)
#define	LPS25H_INT1_SRC_PL   (1 << 1)
#define	LPS25H_INT1_SRC_IA   (1 << 2)

Configuration options
#define	LPS25H_USE_SPI   FALSE
	LPS25H SPI interface switch. More...
#define	LPS25H_SHARED_SPI   FALSE
	LPS25H shared SPI switch. More...
#define	LPS25H_USE_I2C   TRUE
	LPS25H I2C interface switch. More...
#define	LPS25H_SHARED_I2C   FALSE
	LPS25H shared I2C switch. More...
#define	LPS25H_USE_ADVANCED   FALSE
	LPS25H advanced configurations switch. More...

LPS25H data structures and types.
Todo: Add support for LPS25H over SPI.
typedef struct LPS25HDriver	LPS25HDriver
	Structure representing a LPS25H driver. More...
#define	_lps25h_methods_alone
	LPS25H specific methods. More...
#define	_lps25h_methods
	LPS25H specific methods with inherited ones. More...
#define	_lps25h_data
	LPS25HDriver specific data. More...

Data Structures
struct	LPS25HConfig
	LPS25H configuration structure. More...
struct	LPS25HVMT
	LPS25H virtual methods table. More...
struct	LPS25HDriver
	LPS25H 2-axis barometer/thermometer class. More...

Functions
static msg_t	lps25hI2CReadRegister (I2CDriver *i2cp, lps25h_sad_t sad, uint8_t reg, uint8_t *rxbuf, size_t n)
	Reads registers value using I2C. More...
static msg_t	lps25hI2CWriteRegister (I2CDriver *i2cp, lps25h_sad_t sad, uint8_t *txbuf, size_t n)
	Writes a value into a register using I2C. More...
static size_t	baro_get_axes_number (void *ip)
	Return the number of axes of the BaseBarometer. More...
static msg_t	baro_read_raw (void *ip, int32_t axes[])
	Retrieves raw data from the BaseBarometer. More...
static msg_t	baro_read_cooked (void *ip, float axes[])
	Retrieves cooked data from the BaseBarometer. More...
static msg_t	baro_set_bias (void *ip, float *bp)
	Set bias values for the BaseBarometer. More...
static msg_t	baro_reset_bias (void *ip)
	Reset bias values for the BaseBarometer. More...
static msg_t	baro_set_sensitivity (void *ip, float *sp)
	Set sensitivity values for the BaseBarometer. More...
static msg_t	baro_reset_sensitivity (void *ip)
	Reset sensitivity values for the BaseBarometer. More...
static size_t	thermo_get_axes_number (void *ip)
	Return the number of axes of the BaseThermometer. More...
static msg_t	thermo_read_raw (void *ip, int32_t axes[])
	Retrieves raw data from the BaseThermometer. More...
static msg_t	thermo_read_cooked (void *ip, float *axis)
	Retrieves cooked data from the BaseThermometer. More...
static msg_t	thermo_set_bias (void *ip, float *bp)
	Set bias values for the BaseThermometer. More...
static msg_t	thermo_reset_bias (void *ip)
	Reset bias values for the BaseThermometer. More...
static msg_t	thermo_set_sensitivity (void *ip, float *sp)
	Set sensitivity values for the BaseThermometer. More...
static msg_t	thermo_reset_sensitivity (void *ip)
	Reset sensitivity values for the BaseThermometer. More...
void	lps25hObjectInit (LPS25HDriver *devp)
	Initializes an instance. More...
void	lps25hStart (LPS25HDriver *devp, const LPS25HConfig *config)
	Configures and activates LPS25H Complex Driver peripheral. More...
void	lps25hStop (LPS25HDriver *devp)
	Deactivates the LPS25H Complex Driver peripheral. More...

Macro Definition Documentation

#define EX_LPS25H_VERSION   "1.1.2"

LPS25H driver version string.

Definition at line 46 of file lps25h.h.

#define EX_LPS25H_MAJOR   1

LPS25H driver version major number.

Definition at line 51 of file lps25h.h.

#define EX_LPS25H_MINOR   1

LPS25H driver version minor number.

Definition at line 56 of file lps25h.h.

#define EX_LPS25H_PATCH   2

LPS25H driver version patch number.

Definition at line 61 of file lps25h.h.

#define LPS25H_BARO_NUMBER_OF_AXES   1U

LPS25H barometer subsystem characteristics.

Note

Sensitivity is expressed as hPa/LSB whereas hPa stand for hectopascal.

Bias is expressed as hPa.

Definition at line 72 of file lps25h.h.

Referenced by baro_get_axes_number(), and lps25hObjectInit().

#define LPS25H_THERMO_NUMBER_OF_AXES   1U

LPS25H thermometer subsystem characteristics.

Note

Sensitivity is expressed as °C/LSB.

Bias is expressed as °C.

Definition at line 85 of file lps25h.h.

Referenced by lps25hObjectInit(), and thermo_get_axes_number().

#define LPS25H_USE_SPI   FALSE

LPS25H SPI interface switch.

If set to TRUE the support for SPI is included.

Note

The default is FALSE.

Definition at line 219 of file lps25h.h.

#define LPS25H_SHARED_SPI   FALSE

LPS25H shared SPI switch.

If set to TRUE the device acquires SPI bus ownership on each transaction.

Note

The default is FALSE. Requires SPI_USE_MUTUAL_EXCLUSION.

Definition at line 229 of file lps25h.h.

#define LPS25H_USE_I2C   TRUE

LPS25H I2C interface switch.

If set to TRUE the support for I2C is included.

Note

The default is TRUE.

Definition at line 238 of file lps25h.h.

#define LPS25H_SHARED_I2C   FALSE

LPS25H shared I2C switch.

If set to TRUE the device acquires I2C bus ownership on each transaction.

Note

The default is FALSE. Requires I2C_USE_MUTUAL_EXCLUSION.

Definition at line 248 of file lps25h.h.

#define LPS25H_USE_ADVANCED   FALSE

LPS25H advanced configurations switch.

If set to TRUE more configurations are available.

Note

The default is FALSE.

Definition at line 257 of file lps25h.h.

#define _lps25h_methods_alone

LPS25H specific methods.

Note

No methods so far, just a common ancestor interface.

Definition at line 430 of file lps25h.h.

#define _lps25h_methods

Value:

_base_object_methods                                                      \
  _lps25h_methods_alone

LPS25H specific methods with inherited ones.

Definition at line 435 of file lps25h.h.

#define _lps25h_data

Value:

/* Driver state.*/                                                        \
  lps25h_state_t            state;                                          \
  /* Current configuration data.*/                                          \
  const LPS25HConfig        *config;                                        \
  /* Barometer subsystem axes number.*/                                     \
  size_t                    baroaxes;                                       \
  /* Barometer subsystem current sensitivity.*/                             \
  float                     barosensitivity;                                \
  /* Barometer subsystem current bias .*/                                   \
  float                     barobias;                                       \
  /* Thermometer subsystem axes number.*/                                   \
  size_t                    thermoaxes;                                     \
  /* Thermometer subsystem current sensitivity.*/                           \
  float                     thermosensitivity;                              \
  /* Thermometer subsystem current bias.*/                                  \
  float                     thermobias;

LPS25HDriver specific data.

Definition at line 451 of file lps25h.h.

#define lps25hBarometerGetAxesNumber

(

devp

)

barometerGetAxesNumber(&((devp)->baro_if))

Return the number of axes of the BaseBarometer.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

the number of axes.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 496 of file lps25h.h.

#define lps25hBarometerReadRaw	(		devp,
			axes
	)		barometerReadRaw(&((devp)->baro_if), axes)

Retrieves raw data from the BaseBarometer.

Note

This data is retrieved from MEMS register without any algebraical manipulation.

The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[out]	axes	a buffer which would be filled with raw data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 517 of file lps25h.h.

#define lps25hBarometerReadCooked	(		devp,
			axes
	)		barometerReadCooked(&((devp)->baro_if), axes)

Retrieves cooked data from the BaseBarometer.

Note

This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.

Final data is expressed as hPa.

The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[out]	axes	a buffer which would be filled with cooked data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 539 of file lps25h.h.

#define lps25hBarometerSetBias	(		devp,
			bp
	)		barometerSetBias(&((devp)->baro_if), bp)

Set bias values for the BaseBarometer.

Note

Bias must be expressed as hPa.

The bias buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[in]	bp	a buffer which contains biases.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 556 of file lps25h.h.

#define lps25hBarometerResetBias

(

devp

)

barometerResetBias(&((devp)->baro_if))

Reset bias values for the BaseBarometer.

Note

Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 571 of file lps25h.h.

#define lps25hBarometerSetSensitivity	(		devp,
			sp
	)		barometerSetSensitivity(&((devp)->baro_if), sp)

Set sensitivity values for the BaseBarometer.

Note

Sensitivity must be expressed as hPa/LSB.

The sensitivity buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[in]	sp	a buffer which contains sensitivities.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 588 of file lps25h.h.

#define lps25hBarometerResetSensitivity

(

devp

)

barometerResetSensitivity(&((devp)->baro_if))

Reset sensitivity values for the BaseBarometer.

Note

Default sensitivities value are obtained from device datasheet.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 602 of file lps25h.h.

#define lps25hThermometerGetAxesNumber

(

devp

)

thermometerGetAxesNumber(&((devp)->thermo_if))

Return the number of axes of the BaseThermometer.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

the number of axes.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 614 of file lps25h.h.

#define lps25hThermometerReadRaw	(		devp,
			axes
	)		thermometerReadRaw(&((devp)->thermo_if), axes)

Retrieves raw data from the BaseThermometer.

Note

This data is retrieved from MEMS register without any algebraical manipulation.

The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[out]	axes	a buffer which would be filled with raw data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 635 of file lps25h.h.

#define lps25hThermometerReadCooked	(		devp,
			axes
	)		thermometerReadCooked(&((devp)->thermo_if), axes)

Retrieves cooked data from the BaseThermometer.

Note

This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.

Final data is expressed as °C.

The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[out]	axes	a buffer which would be filled with cooked data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 657 of file lps25h.h.

#define lps25hThermometerSetBias	(		devp,
			bp
	)		thermometerSetBias(&((devp)->thermo_if), bp)

Set bias values for the BaseThermometer.

Note

Bias must be expressed as °C.

The bias buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[in]	bp	a buffer which contains biases.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 674 of file lps25h.h.

#define lps25hThermometerResetBias

(

devp

)

thermometerResetBias(&((devp)->thermo_if))

Reset bias values for the BaseThermometer.

Note

Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 689 of file lps25h.h.

#define lps25hThermometerSetSensitivity	(		devp,
			sp
	)		thermometerSetSensitivity(&((devp)->thermo_if), sp)

Set sensitivity values for the BaseThermometer.

Note

Sensitivity must be expressed as °C/LSB.

The sensitivity buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	devp	pointer to LPS25HDriver.
[in]	sp	a buffer which contains sensitivities.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 706 of file lps25h.h.

#define lps25hThermometerResetSensitivity

(

devp

)

thermometerResetSensitivity(&((devp)->thermo_if))

Reset sensitivity values for the BaseThermometer.

Note

Default sensitivities value are obtained from device datasheet.

Parameters

[in]

devp

pointer to LPS25HDriver.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 720 of file lps25h.h.

Typedef Documentation

typedef struct LPS25HDriver LPS25HDriver

Structure representing a LPS25H driver.

Definition at line 303 of file lps25h.h.

Enumeration Type Documentation

enum lps25h_sad_t

LPS25H slave address.

Enumerator
LPS25H_SAD_GND	Slave Address when SA0 is to GND
LPS25H_SAD_VCC	Slave Address when SA0 is to VCC

Definition at line 308 of file lps25h.h.

enum lps25h_odr_t

LPS25H output data rate and bandwidth.

Enumerator
LPS25H_ODR_ONE_SHOT	One shot.
LPS25H_ODR_1HZ	Output data rate 1 Hz.
LPS25H_ODR_7HZ	Output data rate 7 Hz.
LPS25H_ODR_12P5HZ	Output data rate 12.5 Hz.
LPS25H_ODR_25HZ	Output data rate 25 Hz.

Definition at line 316 of file lps25h.h.

enum lps25h_avgp_t

LPS25H pressure resolution.

Enumerator
LPS25H_AVGP_8	Number of internal average is 8.
LPS25H_AVGP_32	Number of internal average is 32.
LPS25H_AVGP_128	Number of internal average is 128.
LPS25H_AVGP_512	Number of internal average is 512.

Definition at line 327 of file lps25h.h.

enum lps25h_avgt_t

LPS25H temperature resolution.

Enumerator
LPS25H_AVGT_8	Number of internal average is 8.
LPS25H_AVGT_32	Number of internal average is 32.
LPS25H_AVGT_128	Number of internal average is 128.
LPS25H_AVGT_512	Number of internal average is 512.

Definition at line 337 of file lps25h.h.

enum lps25h_bdu_t

LPS25H block data update.

Enumerator
LPS25H_BDU_CONTINUOUS	Block data continuously updated.
LPS25H_BDU_BLOCKED	Block data updated after reading.

Definition at line 347 of file lps25h.h.

enum lps25h_state_t

Driver state machine possible states.

Enumerator
LPS25H_UNINIT	Not initialized.
LPS25H_STOP	Stopped.
LPS25H_READY	Ready.

Definition at line 355 of file lps25h.h.

Function Documentation

static msg_t lps25hI2CReadRegister ( I2CDriver *  i2cp, lps25h_sad_t  sad, uint8_t  reg, uint8_t *  rxbuf, size_t  n  )

static

Reads registers value using I2C.

Precondition

The I2C interface must be initialized and the driver started.

Parameters

[in]	i2cp	pointer to the I2C interface
[in]	sad	slave address without R bit
[in]	reg	first sub-register address
[out]	rxbuf	pointer to an output buffer
[in]	n	number of consecutive register to read

Returns

the operation status.

Function Class:Not an API, this function is for internal use only.

Definition at line 63 of file lps25h.c.

References i2cMasterTransmitTimeout(), and TIME_INFINITE.

Referenced by baro_read_raw(), and thermo_read_raw().

Here is the call graph for this function:

static msg_t lps25hI2CWriteRegister ( I2CDriver *  i2cp, lps25h_sad_t  sad, uint8_t *  txbuf, size_t  n  )

static

Writes a value into a register using I2C.

Precondition

The I2C interface must be initialized and the driver started.

Parameters

[in]	i2cp	pointer to the I2C interface
[in]	sad	slave address without R bit
[in]	txbuf	buffer containing sub-address value in first position and values to write
[in]	n	size of txbuf less one (not considering the first element)

Returns

the operation status.

Function Class:Not an API, this function is for internal use only.

Definition at line 87 of file lps25h.c.

References i2cMasterTransmitTimeout(), and TIME_INFINITE.

Referenced by lps25hStart(), and lps25hStop().

Here is the call graph for this function:

static size_t baro_get_axes_number ( void *  ip )

static

Return the number of axes of the BaseBarometer.

Parameters

[in]

ip

pointer to BaseBarometer interface.

Returns

the number of axes.

Definition at line 103 of file lps25h.c.

References LPS25H_BARO_NUMBER_OF_AXES.

Referenced by thermo_reset_sensitivity().

static msg_t baro_read_raw ( void *  ip, int32_t  axes[]  )

static

Retrieves raw data from the BaseBarometer.

Note

This data is retrieved from MEMS register without any algebraical manipulation.

The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to BaseBarometer interface.
[out]	axes	a buffer which would be filled with raw data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 125 of file lps25h.c.

References I2C_READY, i2cAcquireBus(), i2cReleaseBus(), i2cStart(), LPS25H_READY, lps25hI2CReadRegister(), MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by baro_read_cooked(), and thermo_reset_sensitivity().

Here is the call graph for this function:

static msg_t baro_read_cooked ( void *  ip, float  axes[]  )

static

Retrieves cooked data from the BaseBarometer.

Note

This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.

Final data is expressed as hPa.

The axes array must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to BaseBarometer interface.
[out]	axes	a buffer which would be filled with cooked data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 177 of file lps25h.c.

References baro_read_raw(), LPS25H_READY, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

Here is the call graph for this function:

static msg_t baro_set_bias ( void *  ip, float *  bp  )

static

Set bias values for the BaseBarometer.

Note

Bias must be expressed as hPa.

The bias buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to BaseBarometer interface.
[in]	bp	a buffer which contains biases.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 212 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t baro_reset_bias ( void *  ip )

static

Reset bias values for the BaseBarometer.

Note

Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in]

ip

pointer to BaseBarometer interface.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 238 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t baro_set_sensitivity ( void *  ip, float *  sp  )

static

Set sensitivity values for the BaseBarometer.

Note

Sensitivity must be expressed as hPa/LSB.

The sensitivity buffer must be at least the same size of the BaseBarometer axes number.

Parameters

[in]	ip	pointer to BaseBarometer interface.
[in]	sp	a buffer which contains sensitivities.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 266 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t baro_reset_sensitivity ( void *  ip )

static

Reset sensitivity values for the BaseBarometer.

Note

Default sensitivities value are obtained from device datasheet.

Parameters

[in]

ip

pointer to BaseBarometer interface.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 291 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static size_t thermo_get_axes_number ( void *  ip )

static

Return the number of axes of the BaseThermometer.

Parameters

[in]

ip

pointer to BaseThermometer interface.

Returns

the number of axes.

Definition at line 314 of file lps25h.c.

References LPS25H_THERMO_NUMBER_OF_AXES.

Referenced by thermo_reset_sensitivity().

static msg_t thermo_read_raw ( void *  ip, int32_t  axes[]  )

static

Retrieves raw data from the BaseThermometer.

Note

This data is retrieved from MEMS register without any algebraical manipulation.

The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to BaseThermometer interface.
[out]	axes	a buffer which would be filled with raw data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 336 of file lps25h.c.

References I2C_READY, i2cAcquireBus(), i2cReleaseBus(), i2cStart(), LPS25H_READY, lps25hI2CReadRegister(), MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_read_cooked(), and thermo_reset_sensitivity().

Here is the call graph for this function:

static msg_t thermo_read_cooked ( void *  ip, float *  axis  )

static

Retrieves cooked data from the BaseThermometer.

Note

This data is manipulated according to the formula cooked = (raw * sensitivity) - bias.

Final data is expressed as °C.

The axes array must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to BaseThermometer interface.
[out]	axis	a buffer which would be filled with cooked data.

Returns

The operation status.

Return values

MSG_OK	if the function succeeded.
MSG_RESET	if one or more I2C errors occurred, the errors can be retrieved using i2cGetErrors().
MSG_TIMEOUT	if a timeout occurred before operation end.

Definition at line 390 of file lps25h.c.

References LPS25H_READY, objGetInstance, osalDbgAssert, osalDbgCheck, and thermo_read_raw().

Referenced by thermo_reset_sensitivity().

Here is the call graph for this function:

static msg_t thermo_set_bias ( void *  ip, float *  bp  )

static

Set bias values for the BaseThermometer.

Note

Bias must be expressed as °C.

The bias buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to BaseThermometer interface.
[in]	bp	a buffer which contains biases.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 422 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t thermo_reset_bias ( void *  ip )

static

Reset bias values for the BaseThermometer.

Note

Default biases value are obtained from device datasheet when available otherwise they are considered zero.

Parameters

[in]

ip

pointer to BaseThermometer interface.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 449 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t thermo_set_sensitivity ( void *  ip, float *  sp  )

static

Set sensitivity values for the BaseThermometer.

Note

Sensitivity must be expressed as °C/LSB.

The sensitivity buffer must be at least the same size of the BaseThermometer axes number.

Parameters

[in]	ip	pointer to BaseThermometer interface.
[in]	sp	a buffer which contains sensitivities.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 478 of file lps25h.c.

References LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, and osalDbgCheck.

Referenced by thermo_reset_sensitivity().

static msg_t thermo_reset_sensitivity ( void *  ip )

static

Reset sensitivity values for the BaseThermometer.

Note

Default sensitivities value are obtained from device datasheet.

Parameters

[in]

ip

pointer to BaseThermometer interface.

Returns

The operation status.

Return values

MSG_OK

if the function succeeded.

Definition at line 504 of file lps25h.c.

References baro_get_axes_number(), baro_read_cooked(), baro_read_raw(), baro_reset_bias(), baro_reset_sensitivity(), baro_set_bias(), baro_set_sensitivity(), LPS25H_READY, MSG_OK, objGetInstance, osalDbgAssert, osalDbgCheck, thermo_get_axes_number(), thermo_read_cooked(), thermo_read_raw(), thermo_reset_bias(), thermo_set_bias(), and thermo_set_sensitivity().

Here is the call graph for this function:

void lps25hObjectInit

(

LPS25HDriver *

devp

)

Initializes an instance.

Parameters

[out]

devp

pointer to the LPS25HDriver object

Function Class:Initializer, this function just initializes an object and can be invoked before the kernel is initialized.

Definition at line 550 of file lps25h.c.

References LPS25HDriver::baro_if, LPS25H_BARO_NUMBER_OF_AXES, LPS25H_STOP, LPS25H_THERMO_NUMBER_OF_AXES, LPS25HDriver::thermo_if, BaseThermometer::vmt, BaseBarometer::vmt, and LPS25HDriver::vmt.

void lps25hStart	(	LPS25HDriver *	devp,
		const LPS25HConfig *	config
	)

Configures and activates LPS25H Complex Driver peripheral.

Parameters

[in]	devp	pointer to the LPS25HDriver object
[in]	config	pointer to the LPS25HConfig object

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 572 of file lps25h.c.

References I2CDriver::config, i2cAcquireBus(), LPS25HConfig::i2cp, i2cReleaseBus(), i2cStart(), LPS25H_READY, LPS25H_STOP, lps25hI2CWriteRegister(), osalDbgAssert, osalDbgCheck, and osalThreadSleepMilliseconds.

Here is the call graph for this function:

void lps25hStop

(

LPS25HDriver *

devp

)

Deactivates the LPS25H Complex Driver peripheral.

Parameters

[in]

devp

pointer to the LPS25HDriver object

Function Class:Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 669 of file lps25h.c.

References i2cAcquireBus(), i2cReleaseBus(), i2cStart(), i2cStop(), LPS25H_READY, LPS25H_STOP, lps25hI2CWriteRegister(), osalDbgAssert, and osalDbgCheck.

Here is the call graph for this function:
