nil_thread Struct Reference

Structure representing a thread. More...

#include <ch.h>

Collaboration diagram for nil_thread:

Data Fields
struct port_context	ctx
	Processor context. More...
tstate_t	state
	Thread state. More...
volatile sysinterval_t	timeout
	Timeout counter, zero if disabled. More...
eventmask_t	epmask
	Pending events mask. More...
msg_t	sntmsg
	Sent message. More...
stkalign_t *	wabase
	Thread stack boundary. More...
msg_t	msg
	Wake-up/exit message. More...
void *	p
	Generic pointer. More...
os_instance_t *	nsp
	Pointer to nil base struct. More...
thread_reference_t *	trp
	Pointer to thread reference. More...
threads_queue_t *	tqp
	Pointer to thread queue. More...
thread_t *	tp
	Pointer to thread. More...
semaphore_t *	semp
	Pointer to semaphore. More...
eventmask_t	ewmask
	Enabled events mask. More...

Detailed Description

Structure representing a thread.

Definition at line 514 of file ch.h.

Field Documentation

ctx

struct port_context nil_thread::ctx

Processor context.

Definition at line 515 of file ch.h.

state

tstate_t nil_thread::state

Thread state.

Definition at line 516 of file ch.h.

Referenced by chMsgRelease(), chSchGoSleepTimeoutS(), chSysInit(), chThdExit(), nil_find_thread(), and nil_ready_all().

msg

msg_t nil_thread::msg

Wake-up/exit message.

Definition at line 520 of file ch.h.

Referenced by chThdExit().

p

void* nil_thread::p

Generic pointer.

Definition at line 521 of file ch.h.

Referenced by nil_find_thread(), and nil_ready_all().

nsp

os_instance_t* nil_thread::nsp

Pointer to nil base struct.

Definition at line 522 of file ch.h.

trp

thread_reference_t* nil_thread::trp

Pointer to thread reference.

Definition at line 523 of file ch.h.

Referenced by chThdSuspendTimeoutS().

tqp

threads_queue_t* nil_thread::tqp

Pointer to thread queue.

Definition at line 524 of file ch.h.

Referenced by chThdEnqueueTimeoutS().

tp

thread_t* nil_thread::tp

Pointer to thread.

Definition at line 525 of file ch.h.

Referenced by chMsgSend(), and chThdExit().

semp

semaphore_t* nil_thread::semp

Pointer to semaphore.

Definition at line 527 of file ch.h.

Referenced by chSemWaitTimeoutS().

ewmask

eventmask_t nil_thread::ewmask

Enabled events mask.

Definition at line 530 of file ch.h.

Referenced by chEvtWaitAllTimeout(), chEvtWaitAnyTimeout(), and chEvtWaitOneTimeout().

timeout

volatile sysinterval_t nil_thread::timeout

Timeout counter, zero if disabled.

Definition at line 533 of file ch.h.

Referenced by chSchGoSleepTimeoutS(), and chSysTimerHandlerI().

epmask

eventmask_t nil_thread::epmask

Pending events mask.

Definition at line 536 of file ch.h.

Referenced by chEvtSignalI(), chEvtWaitAllTimeout(), chEvtWaitAnyTimeout(), and chEvtWaitOneTimeout().

sntmsg

msg_t nil_thread::sntmsg

Sent message.

Definition at line 539 of file ch.h.

Referenced by chMsgSend().

wabase

stkalign_t* nil_thread::wabase

Thread stack boundary.

Definition at line 542 of file ch.h.

Referenced by chSysInit().
