Collaboration diagram for Virtual Timers:

Detailed Description

Time and Virtual Timers related APIs and services.

Functions
static void	vt_init (delta_list_t *dlhp)
	Delta list initialization. More...

static bool	vt_is_empty (delta_list_t *dlhp)
	List empty check. More...

static bool	vt_is_last (delta_list_t dlhp, delta_list_t dlp)
	Last timer in the list check. More...

static bool	vt_is_first (delta_list_t dlhp, delta_list_t dlp)
	Fist timer in the list check. More...

static bool	vt_is_timer (delta_list_t dlhp, delta_list_t dlp)
	Timer check. More...

static void	vt_insert_after (delta_list_t dlhp, delta_list_t dlp, sysinterval_t delta)
	Inserts an element after another header element. More...

static void	vt_insert_before (delta_list_t dlhp, delta_list_t dlp, sysinterval_t delta)
	Inserts an element before another header element. More...

static void	vt_insert (delta_list_t dlhp, delta_list_t dlep, sysinterval_t delta)
	Inserts an element in a delta list. More...

static delta_list_t *	vt_remove_first (delta_list_t *dlhp)
	Dequeues an element from the delta list. More...

static delta_list_t *	vt_dequeue (delta_list_t *dlp)
	Dequeues an element from the delta list. More...

static void	vt_set_alarm (systime_t now, sysinterval_t delay)
	Alarm time setup. More...

static void	vt_insert_first (virtual_timers_list_t vtlp, virtual_timer_t vtp, systime_t now, sysinterval_t delay)
	Inserts a timer as first element in a delta list. More...

static void	vt_enqueue (virtual_timers_list_t vtlp, virtual_timer_t vtp, sysinterval_t delay)
	Enqueues a virtual timer in a virtual timers list. More...

void	_vt_init (void)
	Virtual Timers initialization. More...

void	chVTDoSetI (virtual_timer_t vtp, sysinterval_t delay, vtfunc_t vtfunc, void par)
	Enables a one-shot virtual timer. More...

void	chVTDoResetI (virtual_timer_t *vtp)
	Disables a Virtual Timer. More...

sysinterval_t	chVTGetRemainingIntervalI (virtual_timer_t *vtp)
	Returns the remaining time interval before next timer trigger. More...

void	chVTDoTickI (void)
	Virtual timers ticker. More...

static void	chVTObjectInit (virtual_timer_t *vtp)
	Initializes a `virtual_timer_t` object. More...

static systime_t	chVTGetSystemTimeX (void)
	Current system time. More...

static systime_t	chVTGetSystemTime (void)
	Current system time. More...

static sysinterval_t	chVTTimeElapsedSinceX (systime_t start)
	Returns the elapsed time since the specified start time. More...

static bool	chVTIsSystemTimeWithinX (systime_t start, systime_t end)
	Checks if the current system time is within the specified time window. More...

static bool	chVTIsSystemTimeWithin (systime_t start, systime_t end)
	Checks if the current system time is within the specified time window. More...

static bool	chVTGetTimersStateI (sysinterval_t *timep)
	Returns the time interval until the next timer event. More...

static bool	chVTIsArmedI (const virtual_timer_t *vtp)
	Returns `true` if the specified timer is armed. More...

static bool	chVTIsArmed (const virtual_timer_t *vtp)
	Returns `true` if the specified timer is armed. More...

static void	chVTResetI (virtual_timer_t *vtp)
	Disables a Virtual Timer. More...

static void	chVTReset (virtual_timer_t *vtp)
	Disables a Virtual Timer. More...

static void	chVTSetI (virtual_timer_t vtp, sysinterval_t delay, vtfunc_t vtfunc, void par)
	Enables a virtual timer. More...

static void	chVTSet (virtual_timer_t vtp, sysinterval_t delay, vtfunc_t vtfunc, void par)
	Enables a virtual timer. More...

Function Documentation

◆ vt_init()

static void vt_init ( delta_list_t * dlhp )

inlinestatic

Delta list initialization.

Parameters

[out] dlhp pointer to the delta list header

Function Class:: Not an API, this function is for internal use only.

Definition at line 58 of file chvt.c.

References ch_delta_list::delta, ch_delta_list::next, and ch_delta_list::prev.

Referenced by _vt_init().

◆ vt_is_empty()

static bool vt_is_empty ( delta_list_t * dlhp )

inlinestatic

List empty check.

Parameters

[in] dlhp pointer to the delta list header

Function Class:: Not an API, this function is for internal use only.

Definition at line 72 of file chvt.c.

References ch_delta_list::next.

Referenced by chVTDoResetI(), chVTDoTickI(), and vt_enqueue().

◆ vt_is_last()

static bool vt_is_last	(	delta_list_t *	dlhp,
		delta_list_t *	dlp
	)

inlinestatic

Last timer in the list check.

Parameters

[in]	dlhp	pointer to the delta list header
[in]	dlp	pointer to the delta list element

Function Class:: Not an API, this function is for internal use only.

Definition at line 85 of file chvt.c.

References ch_delta_list::next.

◆ vt_is_first()

static bool vt_is_first	(	delta_list_t *	dlhp,
		delta_list_t *	dlp
	)

inlinestatic

Fist timer in the list check.

Parameters

[in]	dlhp	pointer to the delta list header
[in]	dlp	pointer to the delta list element

Function Class:: Not an API, this function is for internal use only.

Definition at line 98 of file chvt.c.

References ch_delta_list::next.

Referenced by chVTDoResetI().

◆ vt_is_timer()

static bool vt_is_timer	(	delta_list_t *	dlhp,
		delta_list_t *	dlp
	)

inlinestatic

Timer check.

Parameters

[in]	dlhp	pointer to the delta list header
[in]	dlp	pointer to the delta list element

Function Class:: Not an API, this function is for internal use only.

Definition at line 111 of file chvt.c.

◆ vt_insert_after()

static void vt_insert_after	(	delta_list_t *	dlhp,
		delta_list_t *	dlp,
		sysinterval_t	delta
	)

inlinestatic

Inserts an element after another header element.

Parameters

[in]	dlhp	pointer to the delta list header element
[in]	dlp	element to be inserted after the header element
[in]	delta	delta of the element to be inserted

Function Class:: Not an API, this function is for internal use only.

Definition at line 125 of file chvt.c.

References ch_delta_list::delta, ch_delta_list::next, and ch_delta_list::prev.

Referenced by vt_insert_first().

◆ vt_insert_before()

static void vt_insert_before	(	delta_list_t *	dlhp,
		delta_list_t *	dlp,
		sysinterval_t	delta
	)

inlinestatic

Inserts an element before another header element.

Parameters

[in]	dlhp	pointer to the delta list header element
[in]	dlp	element to be inserted before the header element
[in]	delta	delta of the element to be inserted

Function Class:: Not an API, this function is for internal use only.

Definition at line 145 of file chvt.c.

References ch_delta_list::delta, ch_delta_list::next, and ch_delta_list::prev.

Referenced by vt_insert().

◆ vt_insert()

static void vt_insert	(	delta_list_t *	dlhp,
		delta_list_t *	dlep,
		sysinterval_t	delta
	)

inlinestatic

Inserts an element in a delta list.

Parameters

[in]	dlhp	pointer to the delta list header element
[in]	dlep	element to be inserted before the header element
[in]	delta	delta of the element to be inserted

Function Class:: Not an API, this function is for internal use only.

Definition at line 165 of file chvt.c.

References chDbgAssert, ch_delta_list::delta, ch_delta_list::next, and vt_insert_before().

Referenced by vt_enqueue().

Here is the call graph for this function:

◆ vt_remove_first()

static delta_list_t* vt_remove_first ( delta_list_t * dlhp )

inlinestatic

Dequeues an element from the delta list.

Parameters

[in] dlhp pointer to the delta list header

Function Class:: Not an API, this function is for internal use only.

Definition at line 200 of file chvt.c.

References ch_delta_list::next, and ch_delta_list::prev.

Referenced by chVTDoResetI().

◆ vt_dequeue()

static delta_list_t* vt_dequeue ( delta_list_t * dlp )

inlinestatic

Dequeues an element from the delta list.

Parameters

[in] dlp pointer to the delta list element

Function Class:: Not an API, this function is for internal use only.

Definition at line 216 of file chvt.c.

References ch_delta_list::next, and ch_delta_list::prev.

Referenced by chVTDoResetI(), and chVTDoTickI().

◆ vt_set_alarm()

static void vt_set_alarm	(	systime_t	now,
		sysinterval_t	delay
	)

static

Alarm time setup.

Note: An RFCU fault is registered if the system time skips past (now + delay), the deadline is skipped forward in order to compensate for the event.

Parameters

[in]	now	last known system time
[in]	delay	delay over `now`

Definition at line 234 of file chvt.c.

References CH_CFG_ST_TIMEDELTA, chDbgAssert, chTimeAddX(), chTimeDiffX(), chVTGetSystemTimeX(), and TIME_MAX_SYSTIME.

Referenced by chVTDoResetI(), chVTDoTickI(), and vt_enqueue().

Here is the call graph for this function:

◆ vt_insert_first()

static void vt_insert_first	(	virtual_timers_list_t *	vtlp,
		virtual_timer_t *	vtp,
		systime_t	now,
		sysinterval_t	delay
	)

static

Inserts a timer as first element in a delta list.

Note: This is the special case when the delta list is initially empty.

Definition at line 288 of file chvt.c.

References CH_CFG_ST_TIMEDELTA, chDbgAssert, chTimeAddX(), chTimeDiffX(), chVTGetSystemTimeX(), ch_virtual_timer::dlist, ch_virtual_timers_list::dlist, ch_virtual_timers_list::lasttime, TIME_MAX_SYSTIME, and vt_insert_after().

Referenced by vt_enqueue().

Here is the call graph for this function:

◆ vt_enqueue()

static void vt_enqueue	(	virtual_timers_list_t *	vtlp,
		virtual_timer_t *	vtp,
		sysinterval_t	delay
	)

static

Enqueues a virtual timer in a virtual timers list.

Definition at line 350 of file chvt.c.

References chTimeDiffX(), chVTGetSystemTimeX(), ch_virtual_timer::dlist, ch_virtual_timers_list::dlist, ch_virtual_timers_list::lasttime, vt_insert(), vt_insert_first(), vt_is_empty(), and vt_set_alarm().

Referenced by chVTDoSetI().

Here is the call graph for this function:

◆ _vt_init()

void _vt_init ( void )

Virtual Timers initialization.

Note: Internal use only.

Function Class:: Not an API, this function is for internal use only.

Definition at line 406 of file chvt.c.

References ch, ch_virtual_timers_list::dlist, ch_virtual_timers_list::lasttime, ch_virtual_timers_list::systime, vt_init(), and ch_system::vtlist.

Referenced by chSysInit().

Here is the call graph for this function:

◆ chVTDoSetI()

void chVTDoSetI	(	virtual_timer_t *	vtp,
		sysinterval_t	delay,
		vtfunc_t	vtfunc,
		void *	par
	)

Enables a one-shot virtual timer.

The timer is enabled and programmed to trigger after the delay specified as parameter.

Precondition: The timer must not be already armed before calling this function.

Note: The callback function is invoked from interrupt context.

Parameters

[out]	vtp	the `virtual_timer_t` structure pointer
[in]	delay	the number of ticks before the operation timeouts, the special values are handled as follow: TIME_INFINITE is allowed but interpreted as a normal time specification. TIME_IMMEDIATE this value is not allowed.
[in]	vtfunc	the timer callback function. After invoking the callback the timer is disabled and the structure can be disposed or reused.
[in]	par	a parameter that will be passed to the callback function

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 438 of file chvt.c.

References ch, chDbgCheck, chDbgCheckClassI(), ch_virtual_timer::func, ch_virtual_timer::par, TIME_IMMEDIATE, vt_enqueue(), and ch_system::vtlist.

Referenced by chSchGoSleepTimeoutS(), and chVTSetI().

Here is the call graph for this function:

◆ chVTDoResetI()

void chVTDoResetI ( virtual_timer_t * vtp )

Disables a Virtual Timer.

Precondition: The timer must be in armed state before calling this function.

Parameters

[in] vtp the virtual_timer_t structure pointer

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 461 of file chvt.c.

References ch, chDbgAssert, chDbgCheck, chDbgCheckClassI(), chTimeDiffX(), chVTGetSystemTimeX(), chVTIsArmedI(), ch_delta_list::delta, ch_virtual_timer::dlist, ch_virtual_timers_list::dlist, ch_virtual_timer::func, ch_virtual_timers_list::lasttime, ch_delta_list::next, vt_dequeue(), vt_is_empty(), vt_is_first(), vt_remove_first(), vt_set_alarm(), and ch_system::vtlist.

Referenced by chVTResetI().

Here is the call graph for this function:

◆ chVTGetRemainingIntervalI()

sysinterval_t chVTGetRemainingIntervalI ( virtual_timer_t * vtp )

Returns the remaining time interval before next timer trigger.

Note: This function can be called while the timer is active.

Parameters

[in] vtp the virtual_timer_t structure pointer

Returns: The remaining time interval.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 544 of file chvt.c.

References ch, chDbgAssert, chDbgCheckClassI(), chTimeDiffX(), chVTGetSystemTimeX(), ch_delta_list::delta, ch_virtual_timer::dlist, ch_virtual_timers_list::dlist, ch_virtual_timers_list::lasttime, ch_delta_list::next, and ch_system::vtlist.

Here is the call graph for this function:

◆ chVTDoTickI()

void chVTDoTickI ( void )

Virtual timers ticker.

Note: The system lock is released before entering the callback and re-acquired immediately after. It is callback's responsibility to acquire the lock if needed. This is done in order to reduce interrupts jitter when many timers are in use.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 584 of file chvt.c.

References ch, chDbgCheckClassI(), chSysLockFromISR(), chSysUnlockFromISR(), chTimeAddX(), chTimeDiffX(), chVTGetSystemTimeX(), ch_delta_list::delta, ch_virtual_timer::dlist, ch_virtual_timers_list::dlist, ch_virtual_timer::func, ch_virtual_timers_list::lasttime, ch_delta_list::next, ch_virtual_timer::par, ch_virtual_timers_list::systime, vt_dequeue(), vt_is_empty(), vt_set_alarm(), and ch_system::vtlist.

Referenced by chSysTimerHandlerI().

Here is the call graph for this function:

◆ chVTObjectInit()

static void chVTObjectInit ( virtual_timer_t * vtp )

inlinestatic

Initializes a virtual_timer_t object.

Note: Initializing a timer object is not strictly required because the function chVTSetI() initializes the object too. This function is only useful if you need to perform a chVTIsArmed() check before calling chVTSetI().

Parameters

[out] vtp the virtual_timer_t structure pointer

Function Class:: Initializer, this function just initializes an object and can be invoked before the kernel is initialized.

Definition at line 98 of file chvt.h.

References ch_virtual_timer::func.

◆ chVTGetSystemTimeX()

static systime_t chVTGetSystemTimeX ( void )

inlinestatic

Current system time.

Returns the number of system ticks since the chSysInit() invocation.

Note: The counter can reach its maximum and then restart from zero.; This function can be called from any context but its atomicity is not guaranteed on architectures whose word size is less than systime_t size.

Returns: The system time in ticks.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 116 of file chvt.h.

References ch, ch_virtual_timers_list::systime, and ch_system::vtlist.

Referenced by chThdSleepUntil(), chThdSleepUntilWindowed(), chVTDoResetI(), chVTDoTickI(), chVTGetRemainingIntervalI(), chVTGetSystemTime(), chVTGetTimersStateI(), chVTIsSystemTimeWithinX(), chVTTimeElapsedSinceX(), trace_next(), vt_enqueue(), vt_insert_first(), and vt_set_alarm().

◆ chVTGetSystemTime()

static systime_t chVTGetSystemTime ( void )

inlinestatic

Current system time.

Returns the number of system ticks since the chSysInit() invocation.

Note: The counter can reach its maximum and then restart from zero.

Returns: The system time in ticks.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 135 of file chvt.h.

References chSysLock(), chSysUnlock(), and chVTGetSystemTimeX().

Referenced by chVTIsSystemTimeWithin().

Here is the call graph for this function:

◆ chVTTimeElapsedSinceX()

static sysinterval_t chVTTimeElapsedSinceX ( systime_t start )

inlinestatic

Returns the elapsed time since the specified start time.

Parameters

[in] start start time

Returns: The elapsed time.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 153 of file chvt.h.

References chTimeDiffX(), and chVTGetSystemTimeX().

Here is the call graph for this function:

◆ chVTIsSystemTimeWithinX()

static bool chVTIsSystemTimeWithinX	(	systime_t	start,
		systime_t	end
	)

inlinestatic

Checks if the current system time is within the specified time window.

Note: When start==end then the function returns always false because the time window has zero size.

Parameters

[in]	start	the start of the time window (inclusive)
[in]	end	the end of the time window (non inclusive)

Return values

true	current time within the specified time window.
false	current time not within the specified time window.

Function Class:: This is an X-Class API, this function can be invoked from any context.

Definition at line 171 of file chvt.h.

References chTimeIsInRangeX(), and chVTGetSystemTimeX().

Here is the call graph for this function:

◆ chVTIsSystemTimeWithin()

static bool chVTIsSystemTimeWithin	(	systime_t	start,
		systime_t	end
	)

inlinestatic

Checks if the current system time is within the specified time window.

Note: When start==end then the function returns always false because the time window has zero size.

Parameters

[in]	start	the start of the time window (inclusive)
[in]	end	the end of the time window (non inclusive)

Return values

true	current time within the specified time window.
false	current time not within the specified time window.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 189 of file chvt.h.

References chTimeIsInRangeX(), and chVTGetSystemTime().

Here is the call graph for this function:

◆ chVTGetTimersStateI()

static bool chVTGetTimersStateI ( sysinterval_t * timep )

inlinestatic

Returns the time interval until the next timer event.

Note: The return value is not perfectly accurate and can report values in excess of CH_CFG_ST_TIMEDELTA ticks.; The interval returned by this function is only meaningful if more timers are not added to the list until the returned time.

Parameters

[out] timep pointer to a variable that will contain the time interval until the next timer elapses. This pointer can be NULL if the information is not required.

Returns: The time, in ticks, until next time event.

Return values

false	if the timers list is empty.
true	if the timers list contains at least one timer.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 210 of file chvt.h.

References ch, CH_CFG_ST_TIMEDELTA, chDbgCheckClassI(), chTimeDiffX(), chVTGetSystemTimeX(), ch_delta_list::delta, ch_virtual_timers_list::dlist, ch_virtual_timers_list::lasttime, ch_delta_list::next, and ch_system::vtlist.

Here is the call graph for this function:

◆ chVTIsArmedI()

static bool chVTIsArmedI ( const virtual_timer_t * vtp )

inlinestatic

Returns true if the specified timer is armed.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in] vtp the virtual_timer_t structure pointer

Returns: true if the timer is armed.

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 242 of file chvt.h.

References chDbgCheckClassI(), and ch_virtual_timer::func.

Referenced by chVTDoResetI(), chVTIsArmed(), and chVTResetI().

Here is the call graph for this function:

◆ chVTIsArmed()

static bool chVTIsArmed ( const virtual_timer_t * vtp )

inlinestatic

Returns true if the specified timer is armed.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in] vtp the virtual_timer_t structure pointer

Returns: true if the timer is armed.

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 259 of file chvt.h.

References chSysLock(), chSysUnlock(), and chVTIsArmedI().

Here is the call graph for this function:

◆ chVTResetI()

static void chVTResetI ( virtual_timer_t * vtp )

inlinestatic

Disables a Virtual Timer.

Note: The timer is first checked and disabled only if armed.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in] vtp the virtual_timer_t structure pointer

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 279 of file chvt.h.

References chVTDoResetI(), and chVTIsArmedI().

Referenced by chVTReset(), and chVTSetI().

Here is the call graph for this function:

◆ chVTReset()

static void chVTReset ( virtual_timer_t * vtp )

inlinestatic

Disables a Virtual Timer.

Note: The timer is first checked and disabled only if armed.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in] vtp the virtual_timer_t structure pointer

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 296 of file chvt.h.

References chSysLock(), chSysUnlock(), and chVTResetI().

Here is the call graph for this function:

◆ chVTSetI()

static void chVTSetI	(	virtual_timer_t *	vtp,
		sysinterval_t	delay,
		vtfunc_t	vtfunc,
		void *	par
	)

inlinestatic

Enables a virtual timer.

If the virtual timer was already enabled then it is re-enabled using the new parameters.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in]	vtp	the `virtual_timer_t` structure pointer
[in]	delay	the number of ticks before the operation timeouts, the special values are handled as follow: TIME_INFINITE is allowed but interpreted as a normal time specification. TIME_IMMEDIATE this value is not allowed.
[in]	vtfunc	the timer callback function. After invoking the callback the timer is disabled and the structure can be disposed or reused.
[in]	par	a parameter that will be passed to the callback function

Function Class:: This is an I-Class API, this function can be invoked from within a system lock zone by both threads and interrupt handlers.

Definition at line 325 of file chvt.h.

References chVTDoSetI(), and chVTResetI().

Referenced by chVTSet().

Here is the call graph for this function:

◆ chVTSet()

static void chVTSet	(	virtual_timer_t *	vtp,
		sysinterval_t	delay,
		vtfunc_t	vtfunc,
		void *	par
	)

inlinestatic

Enables a virtual timer.

If the virtual timer was already enabled then it is re-enabled using the new parameters.

Precondition: The timer must have been initialized using chVTObjectInit() or chVTDoSetI().

Parameters

[in]	vtp	the `virtual_timer_t` structure pointer
[in]	delay	the number of ticks before the operation timeouts, the special values are handled as follow: TIME_INFINITE is allowed but interpreted as a normal time specification. TIME_IMMEDIATE this value is not allowed.
[in]	vtfunc	the timer callback function. After invoking the callback the timer is disabled and the structure can be disposed or reused.
[in]	par	a parameter that will be passed to the callback function

Function Class:: Normal API, this function can be invoked by regular system threads but not from within a lock zone.

Definition at line 354 of file chvt.h.

References chSysLock(), chSysUnlock(), and chVTSetI().

Here is the call graph for this function:

Detailed Description

Functions

Function Documentation

◆ vt_init()

◆ vt_is_empty()

◆ vt_is_last()

◆ vt_is_first()

◆ vt_is_timer()

◆ vt_insert_after()

◆ vt_insert_before()

◆ vt_insert()

◆ vt_remove_first()

◆ vt_dequeue()

◆ vt_set_alarm()

◆ vt_insert_first()

◆ vt_enqueue()

◆ _vt_init()

◆ chVTDoSetI()

◆ chVTDoResetI()

◆ chVTGetRemainingIntervalI()

◆ chVTDoTickI()

◆ chVTObjectInit()

◆ chVTGetSystemTimeX()

◆ chVTGetSystemTime()

◆ chVTTimeElapsedSinceX()

◆ chVTIsSystemTimeWithinX()

◆ chVTIsSystemTimeWithin()

◆ chVTGetTimersStateI()

◆ chVTIsArmedI()

◆ chVTIsArmed()

◆ chVTResetI()

◆ chVTReset()

◆ chVTSetI()

◆ chVTSet()
