Type of the factory main object. More...
#include <chfactory.h>
Data Fields | |
| mutex_t | mtx |
| Factory access mutex or semaphore. More... | |
| dyn_list_t | obj_list |
| List of the registered objects. More... | |
| memory_pool_t | obj_pool |
| Pool of the available registered objects. More... | |
| dyn_list_t | buf_list |
| List of the allocated buffer objects. More... | |
| dyn_list_t | sem_list |
| List of the allocated semaphores. More... | |
| memory_pool_t | sem_pool |
| Pool of the available semaphores. More... | |
| dyn_list_t | mbx_list |
| List of the allocated buffer objects. More... | |
| dyn_list_t | fifo_list |
| List of the allocated "objects FIFO" objects. More... | |
Detailed Description
Type of the factory main object.
Definition at line 277 of file chfactory.h.
Field Documentation
| mutex_t ch_objects_factory::mtx |
Factory access mutex or semaphore.
Definition at line 282 of file chfactory.h.
Referenced by _factory_init().
| dyn_list_t ch_objects_factory::obj_list |
List of the registered objects.
Definition at line 289 of file chfactory.h.
Referenced by _factory_init(), chFactoryFindObject(), chFactoryFindObjectByPointer(), chFactoryRegisterObject(), and chFactoryReleaseObject().
| memory_pool_t ch_objects_factory::obj_pool |
Pool of the available registered objects.
Definition at line 293 of file chfactory.h.
Referenced by _factory_init(), chFactoryRegisterObject(), and chFactoryReleaseObject().
| dyn_list_t ch_objects_factory::buf_list |
List of the allocated buffer objects.
Definition at line 298 of file chfactory.h.
Referenced by _factory_init(), chFactoryCreateBuffer(), chFactoryFindBuffer(), and chFactoryReleaseBuffer().
| dyn_list_t ch_objects_factory::sem_list |
List of the allocated semaphores.
Definition at line 304 of file chfactory.h.
Referenced by _factory_init(), chFactoryCreateSemaphore(), chFactoryFindSemaphore(), and chFactoryReleaseSemaphore().
| memory_pool_t ch_objects_factory::sem_pool |
Pool of the available semaphores.
Definition at line 308 of file chfactory.h.
Referenced by _factory_init(), chFactoryCreateSemaphore(), and chFactoryReleaseSemaphore().
| dyn_list_t ch_objects_factory::mbx_list |
List of the allocated buffer objects.
Definition at line 314 of file chfactory.h.
Referenced by _factory_init(), chFactoryCreateMailbox(), chFactoryFindMailbox(), and chFactoryReleaseMailbox().
| dyn_list_t ch_objects_factory::fifo_list |
List of the allocated "objects FIFO" objects.
Definition at line 320 of file chfactory.h.
Referenced by _factory_init(), chFactoryCreateObjectsFIFO(), chFactoryFindObjectsFIFO(), and chFactoryReleaseObjectsFIFO().
